12m 13m crank arm electric aerial work platform
- 2000 Set / Sets per Month
- Shanghai
- T/T L/C D/P D/A Credit Card
- Factory price 10m - 14m Aluminum Aerial Work platform
- Customized available Hydraulic aerial work scissor lift platform
- Hydraulic electric scissor lift platform aerial work platform
- CE ISO Two Masts Full Electric High-altitude Reclaimer Jeakue JK01263
- Factory price CE ISO Battery Vehicle Aerial Work Platform Jeakue JK01265
- CE ISO Electric Crank Arm Aerial Work Platform Jeakue JK01889
Product Details
Place of Origin: | Anhui, China | Brand Name: | Jeakue | Model Number: | JK01889/JK1900 |
Product Description
12m 13m crank arm electric aerial work platform
· With automatic walking function, it is possible under different working conditions, fast, slow walk, only one person may operate the machine at the time of the completion of the lift aerial work continuously, forward, backward, turn, rotation and other movements, more traditional hydraulic platform greatly improving the work efficiency, reduce labor intensity and the number of operating personnel.
• All actions are on the table with the handle control operation, the motor is continuously variable, effectively extending the life of the battery and the motor, the motor only consumes energy at work. Multi-motor structure, walking, lifting, respectively, performed by different motors. Boom in any position, work platforms are safe walking, walking speed with the lift height increases.
· Reverse current brake and mechanical parking brake, the operation is simple, safe and reliable, the service brake automatically compensate for the brake disc brake.
Intelligent charging system, using automatic charger can automatically complete the whole process of charging, the battery is fully charged automatically stop.
· Wide-angle steering system, making the machine has excellent flexibility. With hydraulic automatic steering function. Platform consists of two AC inverter motor drive walking.
Control System
Adopt PLC and CAN bus control mode, the undercarriage, the turntable and platforms were installed on an industrial controller, simplifying the wiring, easy maintenance and repair. Metal plug air defense, protection grade IP65. At the same time the use of advanced CAN bus control circuit is simple, good reliability, maintenance and troubleshooting simple.
· Has upper and lower console (console and floor console platforms) and the upper and lower console commutation switching. When the upper portion of the lower part of the console to control the use of locking function.
· Console the hour meter displays the remaining battery power and other work carried out instructions.
The platform has a foot switch, only depress the foot switch in order to operate.
· Upper and lower console has an emergency stop button, when the operation of unforeseen circumstances, the operator can quickly cut off the power supply to avoid the platform continues to move.
With self-diagnostic function, customers can quickly and timely grasp of their work status of the equipment, better maintenance of the equipment. At the same time the product has the following features:
· Hour meter
· Battery discharge monitor
· Lighting instructions
· Driver operated warning
safety protection
· Working bucket with automatic leveling feature, the tilt angle of the bucket relative to the horizontal plane of the work can not be greater 1.5 °.
The platform reaches a certain amplitude and height, speed and movement speed of the boom automatically restricted. When the machine is parked in the irregularities of the ground Chaoguo 3 °, jib action will be limited.
· Both the upper and lower console shield protection.
· Boom head, cylinder piston rod, etc. There are dust and sediment retention device.
· Undercarriage and turntable position with rings for easy lifting.
• Identify clear and unambiguous.
· Walking equipment, amplitude, time stretching and rotation, will be audible and visual alarm.
Descriptions Of Compact structure electric scissor aerial work platform lift promotion
1.The Mobile Scissor Lift is mainly used for lifting cargos and delivering goods,high-altitude operations.
2.An ideal equipment of safe operation
3.It is charactrized by great loading capacity.
4.Steady ascending and descending
5.New hydraulic system increase safety and protects 4M-18M hydraulic mobile scissor lift
6.Mobile convenient ,easy to work.
7.Economy and practicability.
8.It is applicable in the warehouse and garages and port ,building and so on.
