25t pipe layer SHANTUI SP25Y
oil pipe layer sell factory good price email:martin at
Pipe layer Shantui sell mobile:+86-18202126581
The SP25Y pipe layer is equipped with advanced international technology to provide load feedback and prevent overloading while working on pipe laying projects. With a hydraulic pilot control system, the operations of working devices such as the hook and lifting arm are integrated into a single lever, which is capable of precise, sensitive performance. The machine has been designed to specially measure operating functions in order to prevent overturning or rolling over.
Engine | Shangchai SC11CB184G2B1/Weichai WD10G178E25 | |
Rated power | kW/rpm | 120/1850 |
Ma×imum lifting weight | t | 25 |
Operating weight | kg | 22000 |
L×W×H | mm | 4135×3050×3014 |
Minimum turning radius | mm | 2950 |
Track gauge | mm | 2050 |
Ground length | - | 2635 |
Track shoe width | mm | 560 (610) |
Ground pressure | MPa | 0.07 (0.065/610) |
Ma×imum lifting height | mm | 4400 |
Boom swing amplitude | m | 1.2–5.7 (5.5 Boom) |
Hook speed | m/min | 0–12.0 |
Boom length | m | 5.5 (6.1 Optional) |
