Series

       RSC45-5

Crane spreader

Type

ELME817 or SDJ450

Overall  machine

Overall length

11230mm

Rotary angle

+105°/-195 °

Overall width

4130mm

Side shift distance

+800/-800 mm

Overall height

4780mm

Max. bearing

45000 Kg

Overall quality

71000kg

Applicable range

20/40international standard container

Bearing capacity

The first row

Load center:1965mm

1-4 layer:45000kg

5 layer :43000 kg

Hoisting object

20/40 international standard container

The second row

Load center :3815mm

1-4 layer :31000 kg

5 layer :30000 kg

Out rigger

Max. lifting height

15100mm

Tilting angle

0-60°

The third row

Load center :6315mm

1-3 layer :15000 kg

4 layer :14000 kg

Stroke

7070mm

Max. lifting speed (no-load/load)

420/250 mm/s

Engine

Type

TWD1240VE

Max. traveling speed (no-load/load)

25/21 km/h

Model

Series six cylinder , 4-stroke, central water cooled, turbocharged, electrical spray

Max. falling speed (no-load/load)

360/360 mm/s

Gradeability (no-load/load)

39/32 %

Controlling mode

EDC III full electric control system of CAN general line

Max. traction force

360 kN

Min. turning radius

8000 mm

Rated power

256 kw/2100 r/min

Steering mode

Hydraulic servo-assist steering

Rated torque

1751 Nm/1200 r/min

Wheel base

6000mm

Tail gas emission standard

Euro II

Ground clearance of machine

350mm

Average oil consumption ratio

197g/kwh

Traveling speed

front/rear

(F/R)

The first gear

3.6 km/h

Transmission

Type

CLARK 15.5HR36432

The second gear

8.6 km/h

Gear mode

automatic/manual

The third gear

14.8 km/h

Gear

4 gears for forward and backward

The fourth gear

25 km/h
