Liugong chinese wheel loader 816 and 856 with cheap price
Engine model/modeleYTR4105G69
Rated power/puissance 47KW
Rated load /poids capacite 1600kg
Rated bucket capacity/volume de soute 0.78-1.0m³
Max. breakout force/force max 62±5KN
Max. drawbar pull/ force tractive max 42±5KN
Turning radius outside tires 4370±50mm
Turning radius outside bucket 4695±50mm
Overall dimension L×W×H/dim 7380×2990×3390mm
Operating weight /poids operation 5300±300kg
Ultra-large comfortable safe cab space
·Ultra-large comfortable safe cab space with a panoramic visibility
·Dustproof,sound and shock absorption,heatproof plus ultraviolet radiation-proof
·Panoramic rearview mirror
·Professional-made and sofa driver seat
Duriable and efficient guarantee
·Toughly tested rigid structure proves stable
·The bucket is designed and produced with stiffener board to prevent bending deflection.
·Integral-type board prevent scattering of material and guaranteed the most material loading quantity
Outstanding Z zigzag linkage mechanism
·Powerful breakout force and lifting force means fast lifting and large loading.
·Large rollback angel provides steady material loading ability.
·Controls dump speed:lower dump speed guaranteed the safety of stevedore and linkage mechanism
Air conditioner
Warm wind:working medium | cooling water of diesel engine |
Warm wind:heating capacity | 5000k calories |
Cool wind:electric fan of 24V DC | - |
Capacity data
Fuel tank | 100L |
Coolant system | 27L |
Crankcase | 13L |
Converter-transmission system | 30L |
Axles(differential gear and decelerator) | - |
Front axle | 8L |
Rear axle | 8L |
Hydraulic system | 90L |
Electric system
System | 24V |
Battery | two BA31750T |
Bulb | 24V |
Starting motor | 24V DC |
Engine
Diesel Engine | - |
Rated Rotate Speed | -r/min |
Max. Torque | -r/min |
Fan Diameter (Air Exhaust) | -mm |
Rated Power | 47kw |
Engine YTR4105G69 diesel engine | - |
Water-cooled.4-stroke cycle,direct injection diesel engine | - |
Rated speed | 2400r/min |
Bore X stroke | 4-Φ105mm×120mm |
torque | 220.7N.m±5% |
Fuel consumption per hour in rated power and speed | ≤235g/KW.h |
Equipped with electrical fuel gauge and preserved dip-stick for oil-checking convenience. | - |
Parameters for Entire Loader
Bucket Capacity | 0.78m3 |
Rated Load | 1600kg |
Lifting Time of Acting Arm (Full Load) | -s |
Sum of Three Items | -s |
Traction | -kN |
Max. Breakout Force | 62±5KNkN |
Max. Climbing Gradient | -° |
Weight of Loader (with cab included) | -kg |
Operating Weight | 5300±300kg |
Steering hydraulic system
stype | Articulated frame.Full hydraulic steering |
Steering angle(left and right respectively) | 38° |
Steering pump | gear pump(working pump also) |
Steering cylinder-bore X stroke | Φ60mm×292mm |
Flow | 38L/min |
Relief valve setting | 14MPa |
Tire
Specification | 16/7020 |
Layer | 10 |
Working hydraulic system
system working pressure | 17.5MPa |
Boom cylinder-bore X stroke | Φ80×605mm |
Tilt cylinder-bore X stroke | Φ100×407mm |
