Sinotruck Howo 10M3 Concrete Pump Mixer Truck

Name: Sinotruck Howo 10M3 Concrete Pump Mixer Truck
Brand: Dongfeng
SKU: 140722050
Availability: InStock

US$ 50,000 - 60,000 MOQ: 1 Unit

Key Specifications

Condition:

New

Place of Origin:

Hubei, China

Brand Name:

Dongfeng

Evangel Industrial (Shanghai) Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Hubei, China

Brand Name Dongfeng

Model Number DFD1254GJ2

Weight 25 tons

Dimension(L*W*H) 9650*2500*3800mm

Power(W) 290HP

Certification ISO, CE

Warranty one year

After-sales Service Provided Engineers available to service machinery overseas

Sinotruck Howo 10M3 concrete pump mixer truck

Sinotruck Brand 10M3 concrete mixer truck dimensions

Sinotruck 10M³Concrete Mixer Truck Technical Specification

Chassis Information
Item Name	10M³ Concrete Mixer Truck
Chassis brand	Dongfeng
Chassis model	DFD1254GJ2
Drive type	6×4
Dimension Parameter
Overall dimension (LWH) (mm)	965025003800
Wheel base (mm)	3800+1350
Wheel No.	3
Front/ Rear track (mm)	1986/1860
Weight Parameter
GVW (kg)	25000
Payload weight (kg)	12990
Kerb weight (kg)	11815
Engine Parameter
Model	YC6M290-33
Manufacturer	Yuchai
Horsepower (hp)	290
Displacement / power (ml/kw)	9839/215
Max rated speed(RPM)	2100
Max.Torque (N.m )/r/min	1180/1600
Engine type	6 cylinder, 4 stroke, water cooling, turbocharge
Emission Standard	Euro III
Transmission
Manufacturer	Fuller
Gear Shift	9 forward and 1 reverse speeds
Tyre
Type	10.00R20
Tyre No.	10+1 spare tyre
Cab
Type	flat roof cab
Up-load Special Parameter
Capacity	10M³
Rate of feeding (M³/min)	≥3
Rate of delivery (M³/min)	≥2.0
Rate of residue (M³/min)	≤0.1
Tube service speed	0-12
