4WD Lutong Farm Tractor tractors farming LT604

Model

LT604

Type

4×4

Dimensions (mm)

Length (with front counterweight)

4010

Wide

1890

High (to vent)

2780

Wheelbase (mm)

2236

Front track (mm)

1450

Rear track (mm)

1430-1830

Minimum ground clearance (mm)

310

Minimum turning radius (m)

5.7

Minimum Quality (Kg)

3100

Transmission gears forward / Rear

8/2

Speed range (km / h)

Forward (km / h)

2.95/30.38

Back (km / h)

3.35/12.04

Engine

Model

YT4A2-22

Form

In-line, water-cooled, four-stroke, direct injection, naturally aspirated

Rated power (KW)

44.1

Rated speed (r / min)

2200

Tire Size

Front wheel

8.3-20

Rear wheel

14.9-28

Steering Type

Hydraulic steering

Maximum lifting force (KN)

10.6

PTO shaft type

Rear semi-detached

PTO speed (r / min)

540/760 or 540/1000

PTO power (KW)

37.4

Tillage depth control

Height adjustment, floating control

Maximum traction (KN)

12.5

Counterweight mass (Kg)

Front

270

Rear

320
