Small Farm Tractor KAT Cheap Farm Tractor KAT1204 For Sale
Technical parameters
Model | KAT1004 | KAT1104 | KAT1204 | |||
Engine | Power/speed | kW/r/min | 73.5(100)/2300 | 82(110)/2300 | 91(120)/2200 | |
Specific Fuel Consumption | g/kw.h | ≤230 | ≤235 | ≤220 | ||
Drive Type | / | 4×4 | 4×4 | 4×4 | ||
Dimension(Length/Width/Height) | mm | 4840/2160/2990 | 4840/2160/2990 | 5040/2300/3070 | ||
Wheel Base | mm | 2688 | 2688 | 2688 | ||
Track(Front wheel) | mm | 1552-1948 | 1552-1948 | 1698-2122 | ||
Track(Rear wheel) | mm | 1626-2150 | 1838-2142 | 1626-2150 | ||
Min. Ground Clearance | mm | 460 | 460 | 460 | ||
Min.running weight | kg | 5100 | 5100 | 5700 | ||
Front counter weight | kg | 400 | 400 | 500 | ||
Rated Traction Force | kN | 24 | 26 | 28 | ||
No. of gear | 16F+4R | 16F+4R | 16F+4R | |||
Forward Gear | Speed | km/h | 3-32 | 3-32 | 4-33 | |
Reverse Gear | Speed | km/h | 5-26 | 5-26 | 6-28 | |
Tyre Model | Front Tires | / | 13.6-24 | 13.6-24 | 14.9-24R1 | |
Rear Tires | / | 16.9-34 | 16.9-34 | 18.4-38R1 | ||
Power-output shaft Type | / | Rear position or independent | Rear position or independent | Rear position or independent | ||
power-output shaftRated Speed | r/min | 540/1000 | 540/1000 | 540/1000 | ||
Max. Pull-down piston pull | kN | 25 | 31 | 31 | ||
