Home > Transportation > Truck > Dump Truck > Mini SHACMAN Hydraulic Pump for Dump Truck SX3315DT326

Mini SHACMAN Hydraulic Pump for Dump Truck SX3315DT326

Name: Mini SHACMAN Hydraulic Pump for Dump Truck SX3315DT326
Brand: SHACMAN
SKU: 140721626
Availability: InStock

US$ 10,000 - 100,000 MOQ: 1 Unit

Key Specifications

Drive Wheel:

8x4

Capacity (Load):

31 - 40t

Horsepower:

251 - 350hp

Oriemac Machinery & Equipment (Shanghai) Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai tianjin qingdao

Delivery Detail:

Delivery time depends on order quantity.

Drive Wheel 8x4

Capacity (Load) 31 - 40t

Horsepower 251 - 350hp

Condition New

Transmission Type Automatic

Emission Standard Euro 3

Fuel Type Diesel

Engine Capacity 6 - 8L

Gross Vehicle Weight 14600

Place of Origin Shanxi, China

Brand Name SHACMAN

Model Number SX3315DT326

Dimensions (L x W x H) (mm) 9830x2490x3450

Mini SHACMAN hydraulic pump for dump truck SX3315DT326

Product Description

Model				SX3315DT326
Kerb mass (kg)				14800
Max. total mass (kg)				31000
Max. speed (km/h)				85
Min. turning diameter (m)				24
Min. ground clearance (mm)				314
Max. gradeability (%)				40
Appearance dimensions (mm)		Max. Length		9830
		Max. Width		2490
		Max. Height		3450
Wheel base (mm)				1800+3200+1350
Overhang(front/rear)				1525/1955
Track width (mm) (front/rear)				1939/1939, 1850/1850
Engine				WP10.375 EURIII
Output power ps r. p. m				375/2200
Torque N.m r. p. m				1250 /1200-1600
Cylinder bore×Engine stroke (mm)				126×130
Compression ratio				15.5:1
Fuel consumption for 100km (L)				36
Dimensions of lorry body(L×W×H)				7000×2300×1100
Fuel tank capacity (L)				300 Aluminum alloy
Clutch				GF430 Single-plate, air-assisted, mechanically operated, spring type
Gearbox	Transmission			Fuller RT11509C
	Gear ratio			12.44 8.31 6.09 4.54 3.36 2.47 1.81 1.35 1.00 13.02(R)
Front axle				6.5STR front axle
Rear axle				16T MAN casting axles
Frame				850mm300mm(8+7)
Suspension			Front	Longitudinal semi-elliptic leaf spring type with telescopic absorber
			Rear	Longitudinal parabolic leaf spring balance type
Steering				ZF8098 Integral type power-steering
Cab				F2000 cab, Middle-long flat head,
