Mini rough terrain crane Zoomlion rt750 rough terrain crane 70t price

Type

Ser. No.

Item

Unit

Value

Working performance

1

Max. rated lifting weight × working radius

kg.m/lb.ft

75001×3.0/165346×9.8

2

Max. lifting moment of main boom

kN.m/lbf.ft

2250/2033477

3

Max.lifting moment of longest boom

kN.m/lbf.ft

1160/855614

4

Max. lifting height of main boom

m/ft

41/134.5
(Boom head sheave center)

5

Max. lifting height of jib

m/ft

57/187

Dimensions

6

Outline dimensions (L×W×H)

mm/ft

14896×3396×3842
/48.8×11.1×12.6

7

Distance between outriggers (longitudinal × transversal)

mm/ft

7380×7307
/24.2×23.95

8

Main boom length (completely retracted – completely extended)

mm/ft

12500~38505
/41~126.3

9

Jib length (completely retracted – completely extended)

mm/ft

10000~17002
/3.28~5.58

10

Main boom angle of elevation

°

-3~78

11

Swing range

360°continuously

Working speed

12

Max.speed of single rope on the drum of main winch

m/min

125

13

Boom extension time

s

120

14

Boom retraction time

s

90

15

Boom derricking up time

s

70

16

Boom derricking down time

s

70
