Dongfeng 9cbm 10cbm 12cbm Concrete Mixer Truck

Name: Dongfeng 9cbm 10cbm 12cbm Concrete Mixer Truck
Brand: Dongfeng
SKU: 140720958
Availability: InStock

Oriemac Machinery & Equipment (Shanghai) Co., Ltd.

US$ 2 - 40,000 MOQ: 1 Set

Key Specifications

Condition:

New

Place of Origin:

Hebei, China

Brand Name:

Dongfeng

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai port

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Hebei, China

Brand Name Dongfeng

Model Number EQ1250GJB2

Weight 25000

Dimension(L*W*H) 9500*2500*3800

Power(W) 290HP

Certification ISO,3C

Warranty 1 year

After-sales Service Provided Engineers available to service machinery overseas

Dongfeng 9M³Concrete Mixer Truck Technical Specification

Chassis Information
Item Name	9M³ Concrete Mixer Truck
Chassis brand	Dongfeng
Chassis model	EQ1250GJB2
Drive type	6×4
Dimension Parameter
Overall dimension (LWH) (mm)	950025003800
Wheel base (mm)	3650+1300
Wheel No.	3
Front/ Rear track (mm)	1986/1860
Weight Parameter
GVW (kg)	25000
Payload weight (kg)	12990
Kerb weight (kg)	11815
Engine Parameter
Model	WD615.87
Manufacturer	CNHTC
Horsepower (hp)	290
Displacement / power (ml/kw)	9726/213
Engine type	6 cylinder, 4 stroke, water cooling, inter-cooling
Emission Standard	Euro 2
Transmission
Manufacturer	Fuller
Gear Shift	9 forward and 1 reverse speeds
Tyre
Type	10.00R20
Tyre No.	10+1 spare tyre
Cab
Type	flat roof cab
Up-load Special Parameter
Geometric volume	13.9M³
Mixing Volume	9M³
Angle of inclination ( °)	13.5
Rate of feeding (M³/min)	≥3
Rate of delivery (M³/min)	≥2.0
Rate of residue (M³/min)	≤0.1
Tube service speed	0-14
Range of slump (cm)	5-21
Oil pump	Import from USA or Italy
