5ton Lonking Front End Wheel Loader CDM855E

Name: 5ton Lonking Front End Wheel Loader CDM855E
Brand: Lonking
SKU: 140719288
Availability: InStock

US$ 10,000 - 50,000 MOQ: 1 Unit

Key Specifications

Condition:

New

Brand Name:

Lonking

Model Number:

CDM855E

Oriemac Machinery & Equipment (Shanghai) Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai port China

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Brand Name Lonking

Model Number CDM855E

Place of Origin Fujian, China

Type Front Loader

Moving Type Wheel Loader

Rated Load 5 ton

Certification ISO9001

Warranty Ony year warranty

After-sales Service Provided Engineers available to service machinery overseas

5ton Lonking Wheel Loader CDM855E

5ton front end wheel loader

Overall Data								Steering System
Bucket Capacity (m³)							3	Type			Hydraulic Load Sensor System
Rated Payload(kg)							5000	Cylinders-bore×Stroke(mm)				2-100×324
Operating Weight(kg))							16600±300	Steering Pump				Gear Pump
Traction Force(kN)							155±3	System Pressure(MPa)				16
Breakout Force(kN)							170±3	Flow Rate(L/min/rpm )				176/2200
Travel speeds (km/h):								Steering Angle				±35°
	I				II			Hydraulic System
Forward	11.5				36			Lift Cylinders-bore× Stroke(mm)				2-180×721
Reverse	16							Tilt Cylinder-bore× Stroke(mm)				1-200×563
Engine					WEICHAI WD10G220E21			Model of Working Pump				Gear Pump
Rated Power(kW/rpm)						162/2200		Flow Rate(L/min/rpm )				220/2200
Peak Torque(Nm/rpm)						850/1400-1600		System Pressure(M Pa)				16
Starting Voltage (V)						24		Pilot Control System Pressure(MPa)				2.5
Drive Train								Hydraulic cycle time, rated load in bucket(in second):
Torque Converter			Single-stage, Duo-turbine, 4-element					Raise(Loaded)	Dump	Lower(Empty)			Total
Torque Ratio			4					6	1	4			11
Transmission			Planetary Power shift Transmission					Electrical System
Gear			2F/1R					System Voltage(V)				24
Pressure of Transmission(MPa)							1.2-1.5	Battery (2 in series)(Ah)				120
Main Reducer		Spiral Bevel, 1-stage Reduction						Lamp Voltage(V)				24
Final Reducer		Planetary Reduction						Service Refill Capacity
Tire		23.5-25 L-3 16PR						Fuel Tank(L)				285
Brake System								Hydraulic Tank(L)				285
Service Brake		Single Circuit Caliper ,Dry Brake						Crankshaft(L)				20
Setting Pressure (M Pa)				0.78				Transmission(L)				45
Parking Brake				Air Actuated Caliper Brake				Front Axle(L) /Rear Axle(L)				23/23
