Boom Loader LiuGong ZLG50CN Large Wheel Loader

Name: Boom Loader LiuGong ZLG50CN Large Wheel Loader
Brand: Liugong
SKU: 140719044
Availability: InStock

Oriemac Machinery & Equipment (Shanghai) Co., Ltd.

US$ 61,000 - 71,000 MOQ: 1 Set

Key Specifications

Condition:

New

Brand Name:

Liugong

Model Number:

ZL50CN

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Brand Name Liugong

Model Number ZL50CN

Place of Origin Guangxi, China

Type Front Loader

Moving Type Wheel Loader

Dimension(Long * Breadth * High) 8112*3000*3508mm

Rated Load 5000kg, 5000kg

Certification CE ISO

Warranty 1 Year

After-sales Service Provided Engineers available to service machinery overseas

Boom loader LiuGong ZLG50CN large wheel loader

whatsApp/Tel:+86 18217056032

Bucket capacity	3.0m3
Rated Load	5000kg
Operating weight	16001kg
Torque ratio	2.55
Transmission
Type	conunter shaft-type power shit,semi-automatic
Pressure of transmission	1.6~1.8MPa
Brake
Driving brake	caliper discs,air hydraulic actuated on al four wheel
Parking brake	shoe brake, applied by manually/air control
Emergency brake	using parking brake,applied by air pressure control
Maximum oil pressure	12.3 Mpa
Major reducer
type	spiral bevel,1-stage reduction
speed ratio	4.625
Engine
Rated Power	162kw/2000r/min
Model	WD10G220E23
Type	water-coded,l-arrangement,direct injection,4-stroke diesel engine
Number of cylinder	6
Bore × stroke	121×150mm
Displacement	9.056L
Max.torque	920N.m
Governor	centrifugal all speed governor
Coding system	forced circulation by centrifugal pump pusher type fan
