Help Center90ton Beiben Mining Dump Truck 9042KK 420HP
US$ 10,000 - 100,000
MOQ: 1 Unit
Key Specifications
Get Latest Price
Drive Wheel:
6x4
Capacity (Load):
61 - 70t
Horsepower:
351 - 450hp
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai tianjin qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Hot Sale! Shandong Sinotruk Howo 8*4 Used Tractor Truck Price ListUS$ 38,000 - 39,500MOQ: 1 Set -
HOWO a7 Tractor Head 4*2 Howo a7 Tractor Truck Price ListUS$ 35,000 - 36,100MOQ: 1 Set
-
HOWO Howo a7 Tractor Head 4*2 Howo a7 Tractor Truck Price ListUS$ 35,000 - 36,000MOQ: 1 Set
-
Hot Sale! Shandong Sinotruk Howo 8*4 Used Tractor TruckUS$ 38,000 - 42,000MOQ: 1 Set
-
6x4 Howo Load Tractor Head and Sinotruck 40ton Ethiopia TruckUS$ 35,000 - 36,000MOQ: 1 Set
Drive Wheel
6x4
Capacity (Load)
61 - 70t
Horsepower
351 - 450hp
Condition
New
Transmission Type
Automatic
Emission Standard
Euro 2
Fuel Type
Diesel
Engine Capacity
6 - 8L
Gross Vehicle Weight
28500
Place of Origin
Inner Mongolia, China
Brand Name
Beiben
Model Number
9042KK
Dimensions (L x W x H) (mm)
8630X3600X3950mm
BEIBEN 90Ton Mining Dump Truck 9042KK for sale
Feasures
The vehicles adopts offset driving cabs with single door and single seat, used for mining. The structure of metal framework and stressed-skin exclusive to the domestic heavy-duty trucks makes possible the security of European vehicles at the same level, and can satisfy the requirements of European ECER29 Security Regulations. The vehicle frame is molded by stamping and this guarantees the strength of the crossbeams. The axle technique unique of features such as high reliability, fuel economy, high attendance rate, strengthened structure, all making it suitable for the transportation of heavy goods , used as engineering machinery, under poor working condition such as in mine.
Parameters
| model | 9042KK | ||||
| driving model | 6×4 | ||||
| gross weight | 90000 | ||||
| (Kg) curb weight | 28500 | ||||
| (Kg)load capacity | 41500 | ||||
| (Kg)Frontrear axle load capacity | 25000/40000/40000 | ||||
| exterior dimension | 8630X3600X3950 | ||||
| (mm) wheelbase | 3775+1700 | ||||
| (mm) threadbase | 2866/2690 | ||||
| (mm) front/rear suspension | 1590/1535 | ||||
| (Km/h)top speed | 42 | ||||
| max. slope climbing capacity | 30% | ||||
| (m) turnning diameter | ≤23 | ||||
| approching angle | ≥30° | ||||
| departure angle | ≥40° | ||||
| (mm) min.ground clearance | 330 | ||||
| engine | model | WD12.420 | |||
| type | water-cooled,6 cylinders in line,tubocharge,intercool | ||||
| stroke x broe | 126×155 | ||||
| (L) displacement | 11.596 | ||||
| (KW/r.p.m)rated power | 309/2200 | ||||
| (N.m/r.p.m)max. torque | 1750/1300-1600 | ||||
| clutch | double 400 | ||||
| gearbox | model | Manual ,mechanical gearbox,9 forward gear,1 reverse gear | |||
| (N.m)permission input torque | 2200 | ||||
| tranmission ratio | forward gear12.44; 8.31; 6.09; 4.54; 3.36; 2.47; 1.81; 1.35; 1.00; reverse gear 12.99 | ||||
| axle | front axle(25T),middle and rear axle ratio12.95(BEIBEN 40T) | ||||
| steering system | .Hydralic boosting steering,whole circulation in ball type | ||||
| brake system | double circulation air brake,three sets of braking system | ||||
| service brake-contrallable double circulation foot brake | |||||
| parking brake- hand controlled blow-down springs brake | |||||
| engine exhaust brake | |||||
| frame |
Double-layer composite,the same width 1020mm frame,dimension of section 320x90x8+8(mm), Full- wide straight frame with section of 330 x 80 x 16(8+8)mm, All frame and cabin were stamped by large-scale precision hydraulic press for the one-time molding. |
||||
| front suspension | The longitudinal lay-out style of 13 parabolic leaf-springs, shock absorb | ||||
| rear suspension | 13 parabolic leaf springs with no-independent style balance suspension | ||||
| cab | Offset cabin, Full steel skeleton structure, covered with double layer steel plate, can be tipped forwardly, with air suspension seat for driver. Fully-integrated structure instrument panel , Internal A/C, Radio ,MP3 Player, air horn, sun visor, rear mirror, wiper, gauges (with color indication for safe and unsafe working), monitoring and working signals are conveniently,located within easy reach of the operator. | ||||
| electronics systme | storage battery | 2×165Ah | |||
| generator | 1500W,28V×55A | ||||
| starter | 5.4KW | ||||
| rated voltage | 24V | ||||
| audio device | MP3(SD/USB) | ||||
| Dumper body | front lifting body,body dimension5.6x2.9x1.6m,bottom steel thinkness 14mm with 5 longitudinal frame,edge steel thinkness10mm(material 16Mn),upright front steel with 10mm rear door. 8mm thinkness frame on rear door.four wrap angle,upside and downside hinge | ||||
| A/C | heat from engine coolant system | ||||
| Inner A/C | |||||
| TYRE | 14.00-25 | ||||
| fuel tanker | 400L | ||||
