Home > Products > Vibratory Road Roller > Concrete Road Cutter QG180
Concrete Road Cutter QG180
- Shanghai
- T/T
You May Like
Product Details
| Condition | New | Place of Origin | Jiangsu, China | |
| Brand Name | ANT | Model Number | QG180 | |
| Cutting Depth | 18cm | Diameter of Blade | 35-50cm | |
| Rotary Speed | 65-90m/s | Weight | 136kgs | |
| Dimension(L*W*H) | 133*64*105(L*W*H cm) | Certification | CE | |
| Power Source | gasoline engine | After-sales Service Provided | Overseas service center available |
Product Description
Application of road cutter
- Main: Cutting the surface connection of concrete and asphalt.
- Road repairing for example cutting off the damage of the concrete road or the asphalt road.
- Rectify the road of concrete or asphalt.
- Break down or renew the old house.
- Cutting the concrete prebab products.
- The flex gap’s cutting.
Road cutter technical data
| Model | QG180 |
| Engine | Honda GX390 13HP |
| Engine type | 4stroke,1cylinder,OHV,air-cooled |
| Engine speed | 3600rpm |
| Max cutting depth | 180mm |
| Circle speed | 90m/s |
| Water tank capacity | 32L |
| Blade diameter | 500mm |
| Packing | |
| Weight | 136kgs |
| Dimension | 133*64*105(L*W*H cm) |
| 20GP | 24PCS |
| 40GP | 48PCS |
Road series
| MODEL | QG180F | QG180FX | QG180W |
| Weight kg(lb) | 136(300) | 136(300) | 136(300) |
| Dimension mm(in) | 960(38)×620(24)×1130(44) | 960(38)×620(24)×1130(44) | 960(38)×620(24)×1130(44) |
| Engine | Honda GX390 13HP | Honda GX390 13HP | Honda GX390 13HP |
| Blade dimeter mm(in) | 350(14)/400(16)/450(18)/500(20) | 350(14)/400(16)/450(18)/500(20) | 350(14)/400(16)/450(18)/500(20) |
| Max cutting depth mm(in) | 180(7.0) | 180(7.0) | 180(7.0) |
| Water volum L | 32 | 32 | 32 |



Certificate
Company introduction
Nantong ANT Machinery Co., Ltd., established in 2003, is a modern enterprise specialized in research & development, production and sales of light construction machinery, it is based in the Qidong city of Jiangsu province, which is located in the beautiful and rich Yangtze river delta
The present leading series of products include power trowel, plate compactors, road concrete cutters, tamping rammers, vibrating pokers, power barrow and so on, they have been widely used in different construction fields
Global market
Europe, America, southeast, Asia and Africa
Contact Us
- Nantong Ant Machinery Co., Ltd.
- Contact nameAlice Lu Chat Now
- Phone0086-513-68881082
- AddressNo.280 Fuyuan Road, Nantong, Jiangsu
