Home > Products > Tamping Rammer > Construction Machine Trench Compactor CJ100
Construction Machine Trench Compactor CJ100
- shanghai port
- T/T
You May Like
Product Details
| Place of Origin | Jiangsu, China | Model Number | CJ100 | |
| After-sales Service Provided | Overseas service center available |
Product Description
Construction machine Trench Compactor CJ100
Specifications:
| Model | CJ100 |
| Engine | Honda GX100 3HP |
| Dust bellow | Polyurethane |
| Take off high | 65mm |
| Tamping depth | 55mm |
| Impact frequencty | 600/m |
| Walk speed | 28mm/s |
| Plate size | 340mm*285mm |
| Packing | |
| Weight | 70kgs |
| Dimension | 108*42*74(L*W*H CM) |
| 20GP | 78PCS |
| 40GP | 168PCS |
Applications of Tamping rammer
Rammers are designed to compact loose soils and gravel to prevent settling and to provide a firm, solid base for the placement of footings, concrete slabs, foundations, and other structures.
Maintenance schedule
Certificate of Tamping rammer CJ100
Packing details of tamping rammer
in a 20’container, we can put 78 sets inside;
in a 40’ container, the quantity will be 168 sets.
ANT MACHINERY Tamping Rammer "CJ" series :
Model | Weight | Dimension(cm) | Engine | Jumping Stroke(mm) | Impact Frequency | Impact force(KN) | Plate size(mm) |
CJ60 | 70kg | 80*52*101 | Honda GX160 5.5HP | 40-65 | 420-650/min | 16.7 | 340*285 |
CJ70 | 72kg | 109*77*46 | Robin EH12 4HP | 85 | 680-710/min | 17.0 | 340*290 |
CJ80 | 80kg | 80*52*101 | Honda GX160 5.5HP | 40-65 | 420-650/min | 16.7 | 330*285 |
CJ100 | 70kg | 108*42*74 | Honda GX100 3HP | 65 | 600/min | 15.0 | 340*285 |
Our company is a professional manufacturer, and we have strong technological advantages, complete producer`s equipment and perfect testing technology.
