Original Spare Parts for 5 Ton YTO Diesel Forklift CPCD50

Shanghai Evangel Industrial Co., Ltd. Gold Verified Supplier

5Yrs

US$ 1 - 30,000 MOQ: 1 Unit

Key Specifications

Place of Origin:

Henan, China

Brand Name:

YTO

Model Number:

CPCD50

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai qingdao tianjin

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Henan, China

Brand Name YTO

Model Number CPCD50

Specifications

Original Spare parts for 5 ton YTO Diesel Forklift CPCD50
Original
Quick delivery term

Product Description

Speciality parameter	Model					CPCD50
	Model					CPCD50
	Power type					Diesel
	Rated capacity				kg	5000
	Load center			d	mm	600
	Lift height			h2	mm	3000
	Mast tilt angle (forward/backward)			α/β	Deg	6/12
	Front overhang			L3	mm	590
	Wheel-base			L4	mm	2250
	Tread(front/rear)			b4/b5	mm	1470/1700
Performance parameter	Travel brake					Hydraulic-Foot pedal
	Parking brake					Mechanical-Hand level
	Lift speed(with/without load)				mm/s	350/380
	Lower speed (with/without load)				mm/s	laden<600 without load>300
	Travel speed (with/without load)				km/h	20/21
	Max. gradeability (laden)				%	20
	Max. Towing (with/without load)				kN	42/32
	Weight Distribution with load(pront/rear)					11380/1720
	Weight Distribution without load(pront/rear)					3740/4360
Power, transmission and others	Engine	Model				LR4B3-24
		Manufacturer				YTO
		Rated power			kw	64/2400
		Max.rotation				288/1700
		Displacement				4.578
	Battery	Voltage			V	24
	Battery	Capacity			Ah	2×100
	Gearbox	Transmission type				Hydraulic
	Gearbox	Gears,speed (front/rear)				Ⅱ/Ⅱ
	Tire	type				Pneumatic tyres
		Model	Pront			8.25-15-14PR
		Model	Rear			8.25-15-14PR
Others	Dead.weight				kg	8100
	Free lift height			h4	mm	195
	Fork	Thickness×Width×Length		c×b×a	mm	60×150×1220
	Overall dimensions	Overall length(without forks)		L2	mm	3510
		Overall width		b1	mm	1995
		Overall height	Extended height(mast)	h1	mm	4365
			Lower height(mast)	h3	mm	2500
			Overhead guard	h7	mm	2470
	Min. turning radius			Wa	mm	3300
	Min. under ground clearance	Under mast		m1	mm	195
	Min. under ground clearance	Center of wheel-base		m2	mm	200
