Professional offer CHANGLIN ZL50H Various Model Loader Genuine Spare Part
5.0 Ton CHANGLIN Wheel Loader ZL50H
Description of Wheel Loader ZL50H: Wheel loader ZL50H is a kind of ideal construction machinery (construction equipment/engineering vehicle) to promote your working efficiency. Our wheel loader ZL50H consists of reliable SDEC C6121 engine or generator, 3 forward & 3 reverse power shift transmission. Features of Wheel Loader ZL50H: 1. Bucket automatic leveling ability 2.Combined seal cylinder obtains high seal performance and more reliability 3.Low fuel consumption Applications of Wheel Loader ZL50H: As a kind of construction machinery (construction equipment), wheel loader ZL50H is applied to load or transport material (asphalt, demolition debris, dirt, feed, gravel, logs, raw minerals, recycled material, rock, sand, wood chips, etc.) into or onto another type of machinery (dump truck, conveyor belt, , rail-car, etc.) or place. It also can be in place of excavator. Specifications of Wheel Loader ZL50H:
Overall Dimension | |||
1 |
Length(with bucket on ground) |
Aerican engine |
C6121 engine |
8365(mm) |
8215mm |
||
2 |
Width(to outside of wheels) |
2800(mm) |
|
3 |
Bucket width |
2946(mm) |
|
4 |
Height(To the top of the cab) |
3450(mm) |
|
5 |
Wheel base |
3350(mm) |
|
6 |
Tread |
2200(mm) |
|
7 |
Min. ground clearance |
450(mm) |
|
Main Technical Specification | |||
1 |
Rated load |
5000(Kg) |
|
2 |
Operating weight |
16300KG |
|
3 |
Rated bucket capacity |
3.0(m3) |
|
4 |
Max. breakout force |
160kN |
|
5 |
Max. dump clearance |
3050(mm) |
|
6 |
Dump reach |
1107(mm) |
|
7 |
Dump angle at any position |
≥450 |
|
8 |
Digging depth(with bucket bottom horizontal) |
165(mm) |
|
9 |
Min. turning radius |
||
|
(1) Outside of bucket |
6675(mm) |
|
(2) Outside of rear wheel |
5879(mm) |
||
10 |
Pivot angle frame |
400 |
|
11 |
Oscillating angle of rear axle |
+13o |
|
12 |
Lifting time of bucket |
≤5.8(sec.) |
|
13 |
Lowering time of bucket |
≤3.8(sec.) |
|
14 |
Dumping time |
≤1.2(sec.) |
|
15 |
Traveling speed(Km/h),3 forward and 3 reverse |
||
|
(1) 1st gear |
7.05/9.0 |
|
(2) 2nd gear |
11.7/16.0 |
||
(3) 3rd gear |
34.6/38.24 |
||
Diesel engine | |||
1 |
Model |
6CT AA 8.3-C215 (TIER2) |
ShangChai C6121 engine |
2 |
Type |
Direct injection. Turbocharge. Water cooling |
|
3 |
Rated output |
160 (kW) |
158(Kw) |
4 |
Inter-bore of cylinder/stroke |
114/135 (mm) |
121/152(mm) |
5 |
Total exhaust of cylinder |
8.3 (L) |
10.5(L) |
6 |
Model of starting motor |
42MT |
KB-24V |
7 |
Power of start motor |
8.2(KW) |
7.5(KW) |
8 |
Voltage of starting motor |
24(V) |
24(V) |
9 |
Rated speed |
2200(r/min) |
2200(r/min.) |
10 |
Max. Torque |
998(N.M) |
>843(N.m) |
