Home > Manufacturing & Processing Machinery > Engineering & Construction Machinery > Concrete Machinery > New 6ton Liugong HBT60 Trailer Mounted Concrete Pump on Sale
New 6ton Liugong HBT60 Trailer Mounted Concrete Pump on Sale
US$ 10,000 - 50,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Power Type:
Diesel
Place of Origin:
Guangxi, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
8CBM Liugong Mixer Machine Mobile Concrete Truck Mixer YZH5250GJBHWUS$ 110,000 - 1,100,000MOQ: 1 Set -
Low Price Concrete Mixer With Hydraulic Type Diesel EngineUS$ 10,000 - 100,000MOQ: 1 Set
-
Factory Price 150t/h Roady RD105 Asphalt Mixing PlantUS$ 100,000 - 200,000MOQ: 1 Set
-
China Top Selling 150t/h Roady RD105 Asphalt Mixing PlantUS$ 100,000 - 200,000MOQ: 1 Set
-
High Quality 150t/h Roady RD105 Asphalt Mixing PlantUS$ 100,000 - 200,000MOQ: 1 Set
Condition
New
Power Type
Diesel
Place of Origin
Guangxi, China
Brand Name
Liugong
Model Number
HBT60-9-75Z
Power(W)
132KW
Weight
6ton
Dimension(L*W*H)
6400*2480*2350mm
Certification
ISO CE
Warranty
12 months
After-sales Service Provided
Engineers available to service machinery overseas
Product Description
Liugong Trailer Mounted Concrete Pump HBT60-9-75Z
Specification
1.Power system
World top brand, diesel engine and electrical motor, strong power and low defect.
2.Control system
PLC program controller, well receive or send the signal expediently. It connects with the computer closely. When there is abnormal, it will recover the the original process.
Mixing system is driven by hydraulic motor. The hopper is unique in design, as assure that there is no accumulated material.
Technical Parameter
| No. | Item | Unit | HBT60-9-75Z |
| 1 | Theory Concrete Output (Low / High Pressure) | m3/h | 60 |
| 2 | Concrete Pressure (Low / high pressure) | Mpa | 9 |
| 3 | Hydraulic system pressure | Mpa | 32 |
| 4 | Rotation speed | r/min | 1480 |
| 5 | High / low pressure switch | No | |
| 6 | Distribution valve | Gate valve | |
| 7 | Pumping cylinder diameter/ Stroke | mm | 205/1400 |
| 8 | Main oil pump discharge | ml/r | 190 |
| 9 | Motor power | kw | 75 |
| 10 | Voltage/ Frequency | V/Hz | 380/50 |
| 11 | Hydraulic tank volume | L | 500 |
| 12 | Height of adding material | mm | ≤1500 |
| 13 | Hopper volume | m3 | 0.7 |
| 14 | Total mass | kg | 5500 |
| 15 | Concrete slump | mm | 80-230 |
| 16 | Theory vertical pumping height | m | 100 |
| 17 | Theory direction change times Low/High pressure | times/min | 22 |
| 18 | Dimension: LXWXH | mm | 5850×2050×2260 |
