14.16.18.20 Guage Steel Strut Channel of U Channel C Channel
US$ 10 - 100
MOQ: 500 Pieces
Key Specifications
Get Latest Price
Standard:
AISI, ASTM, BS, DIN, GB, JIS
Dimensions:
41x41
Grade:
Q235
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
14.16.18.20 Guage Steel Strut Channel of U Channel C ChannelUS$ 10 - 100MOQ: 500 Pieces -
12.14.16.18 Guage ASTM Steel Strut Channel of C Channel U ChannelUS$ 10 - 100MOQ: 500 Pieces
-
12.14.16.18 Guage Steel Strut Channel for C Channel U ChannelUS$ 10 - 100MOQ: 500 Pieces
-
ASTM 12.14.16.18 Q238 Steel Strut Channel CombinationsUS$ 10 - 100MOQ: 500 Pieces
-
ASTM Steel Metal Framing Structure Strut ChannelUS$ 20 - 200MOQ: 500 Pieces
Standard
AISI, ASTM, BS, DIN, GB, JIS
Dimensions
41x41
Grade
Q235
Place of Origin
Shandong, China
Brand Name
MR
Model Number
41x41
Shape
U Channel
Application
Steel Structure
Perforated Or Not
Is Perforated
14.16.18.20 Guage Steel Strut Channel of U Channel C Channel
ASTM Steel Strut Channel 14 Guage
We have 7 years experience in the production of steel strut channels of various designs. Our engineers have more than 7 years experience working for the industry. We believe our product and service are second to none. Even better, we can offer you the most competitive price.
Channel Hole Dimension
Pre-Galvanized
| PART # | DESCRIPTION | DIMENSION | FINISH | G. |
| G5841 | Solid, 10 ft. | 1-5/8'' x 1-5/8'' | Pre-Galvanized | 14 g |
| G5842 | Solid, 20 ft. | 1-5/8'' x 1-5/8'' | Pre-Galvanized | 14 g |
| G584H1 | With 9/16 in Hole, 10 ft. | 1-5/8'' x 1-5/8'' | Pre-Galvanized | 14 g |
| G584H2 | With 9/16 in Hole, 20 ft. | 1-5/8'' x 1-5/8'' | Pre-Galvanized | 14 g |
| G584OS1 | With 9/16 in x 1-1/8 in Slot, 10 ft | 1-5/8'' x 1-5/8'' | Pre-Galvanized | 14 g |
| G584OS2 | With 9/16 in x 1-1/8 in Slot, 20 ft | 1-5/8'' x 1-5/8'' | Pre-Galvanized | 14 g |
| G584LS1 | With 13/32 in x 3 in Slot, 10 ft. | 1-5/8'' x 1-5/8'' | Pre-Galvanized | 14 g |
| G584LS2 | With 13/32 in x 3 in Slot, 20 ft. | 1-5/8'' x 1-5/8'' | Pre-Galvanized | 14 g |
| G584A1 | Back-to-Back Welded, 10 ft. | 3-1/4'' x 1-5/8'' | Pre-Galvanized | 14 g |
| G584A2 | Back-to-Back Welded, 20 ft. | 3-1/4'' x 1-5/8'' | Pre-Galvanized | 14 g |
| G584KO1 | With 9/16 in Knock-out, 10 ft. | 1-5/8'' x 1-5/8'' | Pre-Galvanized | 14 g |
| G584KO2 | With 9/16 in Knock-out, 20 ft. | 1-5/8'' x 1-5/8'' | Pre-Galvanized | 14 g |
Green
| PART # | DESCRIPTION | DIMENSION | FINISH | G. |
| G5841POP | Solid, 10 ft. | 1-5/8'' x 1-5/8'' | Green | 14 g |
| G5842POP | Solid, 20 ft. | 1-5/8'' x 1-5/8'' | Green | 14 g |
| G584H1POP | With 9/16 in Hole, 10 ft. | 1-5/8'' x 1-5/8'' | Green | 14 g |
| G584H2POP | With 9/16 in Hole, 20 ft. | 1-5/8'' x 1-5/8'' | Green | 14 g |
| G584OS1POP | With 9/16 in x 1-1/8 in Slot, 10 ft | 1-5/8'' x 1-5/8'' | Green | 14 g |
| G584OS2POP | With 9/16 in x 1-1/8 in Slot, 20 ft | 1-5/8'' x 1-5/8'' | Green | 14 g |
| G584LS1POP | With 13/32 in x 3 in Slot, 10 ft. | 1-5/8'' x 1-5/8'' | Green | 14 g |
| G584LS2POP | With 13/32 in x 3 in Slot, 20 ft. | 1-5/8'' x 1-5/8'' | Green | 14 g |
| G584A1POP | Back-to-Back Welded, 10 ft. | 3-1/4'' x 1-5/8'' | Green | 14 g |
| G584A2POP | Back-to-Back Welded, 20 ft. | 3-1/4'' x 1-5/8'' | Green | 14 g |
| G584KO1POP | With 7/8 in Knock-out, 10 ft | 1-5/8'' x 1-5/8'' | Green | 14 g |
| G584KO2POP | With 7/8 in Knock-out, 20 ft | 1-5/8'' x 1-5/8'' | Green | 14 g |
Special Finishes / Types
| PART # | DESCRIPTION | DIMENSION | FINISH | G. |
| G5841YZ | Gregory Gold, Yellow Zinc Dichromate, 10' | 1-5/8' x 1-5/8' | Special Finishes / Types | 14 g |
| G5842YZ | Gregory Gold, Yellow Zinc Dichromate, 20' | 1-5/8' x 1-5/8' | Special Finishes / Types | 14 g |
| G584GN | Galvannealed WIZcoat, 10' | 1-5/8' x 1-5/8' | Special Finishes / Types | 14 g |
| G584GN | Galvannealed WIZcoat, 20' | 1-5/8' x 1-5/8' | Special Finishes / Types | 14 g |
| G5841PO | Plan, Pickled & Oiled, 10' | 1-5/8' x 1-5/8' | Special Finishes / Types | 14 g |
| G5842PO | Plan, Pickled & Oiled, 20' | 1-5/8' x 1-5/8' | Special Finishes / Types | 14 g |
| G5841HDG | Hot-dipped Galvanized, 10' | 1-5/8' x 1-5/8' | Special Finishes / Types | 14 g |
| G5842HDG | Hot-dipped Galvanized, 20' | 1-5/8' x 1-5/8' | Special Finishes / Types | 14 g |
| G5841SS | Stainless Steel, 10' | 1-5/8' x 1-5/8' | Special Finishes / Types | 14 g |
| G5842SS | Stainless Steel, 20' | 1-5/8' x 1-5/8' | Special Finishes / Types | 14 g |
| G5841PVC | PVC Coated, 10' | 1-5/8' x 1-5/8' | Special Finishes / Types | 14 g |
| G5842PVC | PVC Coated, 20' | 1-5/8' x 1-5/8' | Special Finishes / Types | 14 g |
