Product Details
Place of Origin: | Hebei, China | Material: | Other, Stainless Steel Wire, AISI304/316, SS 201 | Type: | Weave Wire Mesh |
Application: | Other, Filters, for mesh belt,auto-screen changer etc | Weave Style: | Other, Plain ,Dutch ,Twill | Wire Diameter: | 0.03-0.5mm |
Technique: | Woven | Model Number: | MS1986 | Brand Name: | Maishi |
Product Description
Dutch Weave Mesh
Dutch Weave Filter Screen Belt to be used in auto screen changers are widely used in the plastic extrusion industry. for polymer melt filtration in every segment of plastics processing such as blown film, blow molding, sheet and film extrusion, filaments and fibers.
High Tensile Warp AISI 304/316 wire for Auto-Screen changers used in the Poly Extrusion Industry. The AISI 304/316 Warp Wire's Tensile is 1300Mpa-1600Mpa.
Features
1. Zero aperture
2. Light-proof woven
3. Acid and alkali resistance
4. Corrosion and rust resistance
5. High resistance due to tight wire position
6. Extreme low absolute grade of fineness (down to 5 - 6 μm)
7. Heat resistance
Specification
Material: AISI(SUS)304,304L,316,316L,201,202
Width :97mm,127mm,137m,157mm,158mm,159mm etc
Length: 10m,15m,20m,30m,30.48m etc
Plain Weave: The warp and weft are aligned so they form a simple cross-cross pattern. Each weft thread crosses the warp threads by going over one, then under the next, and so on.
Twill Weave: In a twill weave, each weft or filling yarn floats across the warp yarns in a progression of interlaces to the right or left, forming a distinct diagonal line. This diagonal line is also known as a wale. A float is the portion of a yarn that crosses over two or more yarns from the opposite direction.
Plain Dutch Weave:Similar with plain weave, just the weft and warp wire have different wire diameter and different mesh size.
Twill Dutch Weave: Similar with twill weave, just the weft and warp wire have different wire diameter and different mesh size.
Reverse Dutch Weave:Difference from standard Dutch weave lies in the thicker warp wires and less weft wires.
1. Waterproof paper inside, carton outside
2. Customer's special request is avaliable
HEBEI MAISHI dostrictly tested before the goods dispatched from our factory to ensure their quality.Make sure customers get perfect quality.
- Mesh Count inspect
- Thickness inspect
- Thread diameter& Hole size inspect
- Tensile Strength inspect
- Surface Tension test
Hebei Maishi Wire Mesh Manufacture Co.,Ltd ,connected with production of stainless steel woven wire mesh and netting, since 1992, in China. The machinery and apparatus used in production process fully based on the high computer technology, so it is accepted as the only company capable of having TSE ( Chinese Standard Institution ) certificate and ISO 9001:2008, all of our produce according ISO9044:1999, JIS G 3555:2004, and ISO3310/BS410 etc.
We use imported precision slitting machine,can article points precision mesh, plain weave, twill weave.
Our mainly market of stainless steel wire mesh/colth in Germany, UK, Italy, Turkey, Korea, Thailand, Brazil, Mexico, Argentina, Egypt, Ghana, and other parts in the world. We have good reputation in the world with the quality and price. You are welcome to send by email or fax your inquiry for trial orders.
