ss316 stainless steel wire mesh
- 30000 Square Meter / Square Meters per Month
- Xingang
- T/T Credit Card
- Factory BBQ mesh Perforated crimped wire mesh for barbecue with best price and quality
- Hot Selling!High Quality Cheap Chain Link Fence top barbed wire/cyclone fence
- Alibaba Verified China Factory Popular Perimeter fence/Chain Link Fence top barbed wire/cyclone fence
- China Hot Sale High Quality Perimeter fence/Chain Link Fence top barbed wire/cyclone fence
- Alibaba.com Golden Supplier High Quality Perimeter fence/Chain Link Fence top barbed wire/cyclone fence
- Alibaba Made In China Anping Perimeter fence/Chain Link Fence top barbed wire/cyclone fence
Product Details
Place of Origin: | Hebei, China | Material: | Other, Stainless Steel Wire, AISI 304/316/316L | Type: | Weave Wire Mesh |
Application: | Woven Wire Mesh | Weave Style: | Other, Plain ,Dutch ,Twill | Wire Diameter: | 0.025-1.8mm |
Technique: | Woven | Model Number: | WSWM | Brand Name: | Maishi |
Product Description
The production according to ISO9001 quality management system. Mesh produced are from 0.5 mesh per inch to 2800 mesh per inch. Goods exports to NORTH AMERICA, SOUTH AMERICA, EUROPE, ASIA, MIDDLE EAST and AFRICA.
Stainless steel wire mesh specification
Mesh count: 0.5 mesh - 2800 mesh
Wire diameter: 0.025mm - 2.0mm
Weave type: plain, twill, plain dutch, twill dutch, reverse dutch
Material: AISI/SUS 201,202,304,304L,316,316L,310,310S,430
Width: 2FT, 3FT, 4FT, 5FT etc
Standard: A580 , JIS6 , GBT
We can design various types of products according to our customers needs, you can find any products here, for special designs please send your sample to us.
1.Mesh Rolls 2.Mesh Belts 3.Mesh Sheets 4.Mesh Ribbons
5.Mesh Tubes 6.Sintered mesh 7.Crimped mesh 8.Decoration mesh
1. Heat resistance, acid resistance and corrosion resistance and wear.
2. Accurate and stable filtering rate.
3. High mechanical strength .
4. Easy to clean.
5. Suitable for cutting, bending, stamping, drawing, welding and other processing conditions.
1) We pack the mesh with - waterproof paper bag - plastic film - wooden case
2) For small order : if the weight less than 50KG, we can use TNT/FedEx/DHL express to delivery the goods to your door.
3) For big order : usually we use ocean shipping
Payment term : we accept various payment term like Paypal ,West Union , TT ,L/C etc.
High quality is guaranteed by the usage of real material, zero mesh defects, precision weaving and strong structure and finishing. We take strict quality control in each production process and final inspection by our Quality Control System. At Final Inspection, every meter of mesh is inspected for any kind of fault according to our Quality Control System. Only tested, approved, A-Grade mesh is sold to our customers.
We connected with production of stainless steel woven wire mesh and netting, since 1986 in China. The machinery and apparatus used in production process fully based on the high computer technology, so it is accepted as the only company capable of having TSE ( Chinese Standard Institution ) certificate and ISO 9001:2008, all of our produce according ISO9044:1999, JIS G 3555:2004, and ISO3310/BS410 etc.
1. Dedicated and experienced weavers.
2. Consistent quality products.
3. On-time delivery.
4. We have 15 R&D technical staffs, with more than 10 years experience.
5. 90% repeat customers.
6. Reasonable claim refund system.
Mesh – The number of openings per lineal inch.
Aperture- The distance between two adjacent wires
Diameter- The thickness of the wire before weaving
% Open Area- The ratio of the area of the aperture to the area of the mesh expressed in percentage terms
Warp- All wires running length of the cloth as woven
Weft- All wires running across the cloth as woven
Calculating
1. Mesh Count = 25.4mm/D+A
2. Aperture= 25.4mm/Mesh count - Diameter
3. % Open Area= A/(A+D)² X 100%
4. Micron= Aperture(mm) X 1000
Types of weave
1. Plain Weave: also called tabby weave, linen weave or taffeta weave, is the most basic type of weaves. In plain weave, the warp and weft are aligned so they form a simple cross-cross pattern. Each weft thread crosses the warp threads by going over one, then under the next, and so on. The next weft thread goes under the warp threads that its neighbor went over, and vice versa.
2. Twill Weave: In a twill weave, each weft or filling yarn floats across the warp yarns in a progression of interlaces to the right or left, forming a distinct diagonal line. This diagonal line is also known as a wale. A float is the portion of a yarn that crosses over two or more yarns from the opposite direction.
3. Plain Dutch Weave: similar with plain weave, just the weft and warp wire have different wire diameter and different mesh size.
4. Twill Dutch Weave: similar with twill weave, just the weft and warp wire have different wire diameter and different mesh size.
5. Reversed Dutch Weave: difference from standard Dutch weave lies in the thicker warp wires and less
