Maishi group produce security screen mesh used on doors or windows to make your family far away from danger.
Made from high tensile stainless steel, woven into a fine mesh, it is hard to cut and break.
We have full production capability of weaving, flatten, cutting, powder coating for our mesh. Only tested security mesh is selected to guarantee our customer have a high-quality product.
Raw Material:
Galvanized steel wire, Low carbon steel wire, 201 stainless steel wire, 304 stainless steel wire, Marine grade 316 stainless steel wire
Materials |
Mesh Size |
Available Screen Size |
|
304 stainless steel wire Marine grade 316 stainless steel wire 201 stainless steel wire Galvanized steel wire Low carbon steel wire
|
10mesh x 0.8mm |
Width x Length 750mm x 2000mm (2400mm/3000mm) 900mm x 2000mm (2400mm/3000mm) 1000mm x 2000mm (2400mm/3000mm) 1200mm x 2000mm (2400mm/3000mm) 1500mm x 2000mm (2400mm/3000mm) |
10mesh x 0.9mm | ||
11mesh x 0.8mm | ||
11mesh x 0.9mm | ||
12mesh x 0.7mm | ||
14mesh x 0.5mm | ||
14mesh x 0.55mm | ||
14mesh x 0.6mm | ||
Coating Color |
Black/Gray/White epoxy coated |
|
Difference between stainless steel 316 and 304
1) Stainless steel 316
It is high tensile AISI316 stainless steel wire, tolerance(+/-0.01mm), tensile strength can reach to 1100-1150N. The holes are square and the wires are very strong (not sliding), screen surface is flattened after we weave the wires to mesh screen.
Characteristic:
Safe: Not easy to cut and break pass AS5039-2008
Private live: No one can peep at room
Beautiful: Gorgeous surface
Durable: More than 10years Warranty pass AS2331.3.1-2001
2) Stainless steel 304
It was produced by high tensile AISI304 stainless steel wire, tolerance(+/-0.01mm), tensile strength can reach to 1100-1150N. The holes are square and the wires are very strong (not sliding), screen surface is flattened after we weave the wires to mesh screen.
Characteristic:
Safe: Not easy to cut and break pass AS5039-2008
Private live: No one can peep at room
Beautiful: Gorgeous surface
Durable: More than 10years Warranty pass AS2331.3.1-2001
[ Black powder ]
The powder coating we use is CamelPaint black powder or Akzo Nobel podwer coating. can guarantee 10years, no fade.
Our mesh has passed 3006 Hour Salt Spray Tests, and 534 hours UV Test equivalent to 30 years exposure.
security screen mesh
[ Surpasses the below standards ]
1) Knife Shear Test(AS5039-2008)
2) Anti-Jemmy Test(AS509-2008)
3) Pull Test(AS5039-2008)
4) Durable more than 10 years(AS2331.31-2001)
5) 3006 Hour Salt Spray Tests, 534 hours UV Test
Factory show:
Payment:T/T,L/C,WESTERN UNION
We warmly welcome all friend from all over the world to be our business partners.
