Steel Mesh Security Screen

Steel mesh security screen:

[ Material ]

1) Stainless steel 316
It is high tensile AISI316 stainless steel wire, tolerance(+/-0.01mm), tensile strength is more than 900Mpa (900N).

The holes are square and the wires are very strong (not sliding), screen surface is flattened after we weave the wires to mesh screen.
Characteristic:
Safe: Not easy to cut and break pass AS5039-2008
Private live: No one can peep at room
Beautiful: Gorgeous surface
Durable: More than 10years Warranty pass AS2331.3.1-2001

2) Stainless steel 304
It was produced by high tensile AISI304 stainless steel wire, tolerance(+/-0.01mm), tensile strength is more than 780Mpa (780N).

The holes are square and the wires are very strong (not sliding), screen surface is flattened after we weave the wires to mesh screen.
Characteristic:
Safe: Not easy to cut and break pass AS5039-2008
Private live: No one can peep at room
Beautiful: Gorgeous surface
Durable: More than 10years Warranty pass AS2331.3.1-2001

Steel mesh security screen

[ Production Process]

Marine grade stainless, or SAE 316 stainless steel, is a molybdenum-alloyed steel and is the second most common austenite stainless steel (after grade 304).

It is the preferred steel for use in marine environments because of its greater resistance to pitting corrosion than other grades of steel.

The fact that it is negligibly responsive to magnetic fields means that it can be used in applications where a non-magnetic metal is required.

In addition to molybdenum, 316 also contains a number of other elements in varying concentrations.

Like other grades of stainless steel, marine grade stainless steel is a relatively poor conductor of both heat and of electricity.

Steel mesh security screen
[ Passes the below tests ]
1) Knife Shear Test(AS5039-2008)
2) Anti-Jemmy Test(AS509-2008)
3) Pull Test(AS5039-2008)
4) Durable more than 10 years(AS2331.31-2001)
5) 3006 Hour Salt Spray Tests, 534 hours UV Test

[Specification ]
11mesh*0.8mm, 12mesh*0.7mm, 14mesh*0.6mm, 14mesh*0.55mm, 14mesh*0.5mm
750mmx1200mm 910mmx1200mm 1200mmx1500mm
750mmx1500mm 910mmx1500mm 1200mmx2000mm
750mmx2000mm 910mmx2000mm 1200mmx2400mm
750mmx2400mm 910mmx2400mm


Steel mesh security screen

[ Features ]
Excellent flact surface
High tension,Equal aperture and dia
Corrosion resistance,easy to install
10 years not to corrode,face or bubble
Black color filter 60% of UV rays

[ Related Information ]

1) Packing: A piece of waterproof paper between two pieces of mesh,then with polywood cases.
Fumigation certificate supplied.
2) Delivery time: According to the final order. Usually within 15-20 days.
3) Payment: T/T, L/C at sight etc.
