Automatic Square Wiremesh Welding Machine
Characters: strong welded points and bright luster .The mesh doesnt come loose even if cut in parts or being exerted force on parts .Compared with general iron wire ,the products are better in respects of anti-corrosive and anti-rust .
Materials:
Galvanized iron wire, stainless steel wire, PVC coated wire
Usage
They are widely used in industry, agriculture, construction, transport and mining .Such as machine protection cover, ranch fender, garden fence, window protection fender, passage fender, fowl cage, egg basket, foodstuffs basket, etc.
|
Type Parameters |
|
|||
DHW-4 |
DHW-5 |
DHW-6 |
DHW-7 |
|
Welding width |
48" |
60" |
72" |
84" |
Hole size |
1/2"-2" |
1/2"-2" |
1"-3" |
1"-4" |
Wire dia |
0.6-1.5mm |
0.6-2.0mm |
1.2-2.5mm |
1.2-2.7mm |
Welding speed |
<90times/min |
<70times/min |
<70times/min |
<60times/min |
Power |
65KVA*4 |
70KVA*5 |
75KVS*6 |
75KVA*7 |
Rated voltage |
380V 50HZ |
380V 50HZ |
380V 50HZ |
380V 50HZ |
Overall dimension |
3450*1600*1300 |
2750*1600*1300 |
4000*1600*1300 |
4300*600*1300 |
Packaging: in pallets, in plastic film or as per customers’ requirements.
Shipping: within 25days after receiving the prepayment or relevant L/C.
Guarantee and After-sale Service:
1.Warranty: One Year.
2.Enough spare parts of machines could be supplied.
3.All machines were tested and adjusted before delivery.
4.Engineers avaliable to service machinery overseas:Worker-training, installation.etc.
5.24 hours technical support by e-mail or calling service.
Payment: 30%TT in advance and pay off the balance against the copy of B/L.
MOQ: 1 Set
