Recessed Mini Round Square Led Panel Light With Radiator 3/4/6/9/12/15/18/24w

Hubei Derun Lighting Appliance Co., Ltd.
Recessed Mini Round Square Led Panel Light With Radiator 3/4/6/9/12/15/18/24w thumbnail-1
Recessed Mini Round Square Led Panel Light With Radiator 3/4/6/9/12/15/18/24w thumbnail-2
Recessed Mini Round Square Led Panel Light With Radiator 3/4/6/9/12/15/18/24w thumbnail-3
Recessed Mini Round Square Led Panel Light With Radiator 3/4/6/9/12/15/18/24w thumbnail-4
Recessed Mini Round Square Led Panel Light With Radiator 3/4/6/9/12/15/18/24w thumbnail-5
Recessed Mini Round Square Led Panel Light With Radiator 3/4/6/9/12/15/18/24w photo-1
Recessed Mini Round Square Led Panel Light With Radiator 3/4/6/9/12/15/18/24w photo-2
Recessed Mini Round Square Led Panel Light With Radiator 3/4/6/9/12/15/18/24w photo-3
Recessed Mini Round Square Led Panel Light With Radiator 3/4/6/9/12/15/18/24w photo-4
Recessed Mini Round Square Led Panel Light With Radiator 3/4/6/9/12/15/18/24w photo-5
US$ 1.5 - 8.5 MOQ: 1000 Pieces
Key Specifications
Get Latest Price
LED Light Source:
SMD2835
Warranty(Years):
3
Input Voltage(V):
AC85-265V
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or Ningbo port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
LED Light Source SMD2835
Warranty(Years) 3
Input Voltage(V) AC85-265V
Lamp Power(W) 6
Lamp Luminous Flux(lm) 540
Lamp Luminous Efficiency(lm/w) 90
Color Temperature(CCT) Other, warm white /pure white /cool white
Working Temperature(℃) -20, 50
Working Lifetime(Hour) 50000
Lamp Body Material Aluminum Alloy
IP Rating IP33
Certification CE, SAA, UL
Place of Origin Hubei, China
Brand Name Derun lighting
Model Number DR-MD120R-6W
Aluminum alloy mini recessed led panel light with radiator 3/4/6/9/12/15/18/24W
Product Description





       The Detailed information

 Recessed mini round square led panel light with radiator 3/4/6/9/12/15/18/24w



Model No.Size (D×H)Cut-out sizePowerLumen
DR-MD90R-3WØ90× 14mmØ75mm3W270lm
DR-MD100R-4WØ100× 14mmØ90mm4W360lm
DR-MD120R-6WØ120× 14mmØ110mm6W540lm
DR-MD145R-9WØ145× 14mmØ135mm9W810lm
DR-MD170R-12WØ170× 14mmØ160mm12W1080lm
DR-MD190R-15WØ190× 14mmØ175mm15W1350lm
DR-MD225R-18WØ225× 14mmØ205mm18W1620lm
DR-MD300R-24WØ300× 14mmØ275mm24W2160lm
Model No.Size (L×W×H)Cut-out SizePowerLumen
DR-MS85R-3W85×85×15mm75×75mm3W270lm
DR-MS100R-4W100×100×15mm90×90mm4W360lm
DR-MS120R-6W120×120×15mm105×105mm6W540lm
DR-MS146R-9W146×146×15mm135×135mm9W810lm
DR-MS174R-12W174×174×15mm155×155mm12W 1080lm
DR-MS200R-15W200×200×15mm182×182mm15W1350lm
DR-MS225R-18W225×225×15mm205×205mm18W1620lm
DR-MS300R-24W300×300×15mm278×278mm24W2160lm



      Product Show



Recessed mini round square led panel light with radiator 3/4/6/9/12/15/18/24w

 Recessed mini round square led panel light with radiator 3/4/6/9/12/15/18/24w

      Application

  1. Home lighting, school, hospital, office, residential area lighting.
  2. Bar, restaurant, hotel, cinema, plaza, supermarket,museum.
  3. Parking ground, subway station, railway station, airport,etc.

Recessed mini round square led panel light with radiator 3/4/6/9/12/15/18/24w

        Feature

  1. We use high power LEDs, long life and Good heat dissipation.
  2. Self-developed constant current power for power supply circuit greatly improve the stability of our products.
  3. Long Life: more than 50,000 hours
  4. Efficiency: Over 80% energy saving than energy-saving lamp.Over 90% energy saving than incandescent lamp!
  5. Good heat dissipation by unique heat-sink design
  6. OEM, ODM, and customer design are available
  7. Flexible Voltage: Use led panel light  in AC85-256V environment
  8. Reliable Protection function against open circuit, short circuit, overload,overvoltage and under voltage risk
  9. No Mercury Inside, No UV, No IR, good for your health
  10. Flicker-Free Lighting: Eliminate eye strain and headaches
  11. CE, RoHS certifications
  12. 3 years warranty

Recessed mini round square led panel light with radiator 3/4/6/9/12/15/18/24w



          Installation



               Package&Shipping                                                                                         1.   1piece/box.         2.     10/30/40/50pcs per carton.      3.      color box/customer demand.

 Recessed mini round square led panel light with radiator 3/4/6/9/12/15/18/24wRecessed mini round square led panel light with radiator 3/4/6/9/12/15/18/24wRecessed mini round square led panel light with radiator 3/4/6/9/12/15/18/24w

Company Information



               Our company

Recessed mini round square led panel light with radiator 3/4/6/9/12/15/18/24w



Our Services





7*24 hours are all accessible for your any requirement !!!  Recessed mini round square led panel light with radiator 3/4/6/9/12/15/18/24w
