Specifications

Monocular Metallurgical Microscope
1. Monocular Head Inclined At 45 degree
2. Ball beating Quadruple Nosepiece

Monocular Metallurgical Microscope

Technical Parameters

Model	BXJD-100
Viewing head	Monocular Head Inclined At 45°
Nosepiece	Ball beating Quadruple Nosepiece
Eyepiece	WF10X,12.5X
Objective	Metallurgical objectives 10X, 40X,100X(S,O)
Stage	Double layers mechanical stage 135*140mm,Moving range 70*50mm Double Layer Mechanical Stage 242*172mm moving range 75*50mm
Focusing	Coaxial coarse and fine focusing adjustment with rack and pinion mechanism fine focusing scale value 0.002mm
Illumination	Built-in illumination, halogen lamp 6V/20W, Power supply 220V
Filter	Blue, green, yellow

Packaging & Shipping

• Pakckages conform to International Standards
• Forwarders are reliable
• We try our best to deliver the goods to the customers timely and safely





after the describtion of Product, the details of Company are showed below:

Company Information









































































































• Established in 1999, cover 20000 square meters, over 1000 employees,
• 15 years production experience, 50 professional engineers, strong research team and quality control team
• Certificated by ISO9001, ISO14001, ISO3485, CE, MET, NSF49, EN12469

Certifications



























































Exhibition



Our Service

      Skype: liu.bella49

                  QQ: 1801039759

I will try my best to serve you, looking forawrd to your inquiry.
