Model

11234BBC86

Normal size

1.2 meter( 4' )

External Dimensions
(W x D x H)

1370 x 760 x 2100 mm
53.9" x 29.9" x 86.6"

Internal Work Area, Dimensions
(W x D x H)

1220x600x630mm    48' ' x23.6' ' x24.8' '

Internal Work Area, Space

0.73 m2

Average Airflow
Velocity

Inflow 0.46 m/s

Downflow 0.33 m/s

safety opening height

200mm

max opening

400mm

front window

two-layer laminated toughened glass > 5mm

Noise

≤ 61dB

Power

< =700W

water and gas tap

water tap: 1      gas tap: 1

waterproof socket

2; total consumption 500w

Display

LCD display

Exhaust Volume
with Thimble
Duct

CBV Exhaust Volume 611 m3 / h (360 cfm)

Static Pressure at CBV
Exhaust Volume 39 Pa / 0.15 in H2O

air supply filter

ULPA filter, efficiency > 99.999% for particle size between 0.1 to 0.2 microns

exhaust filter

2 pieces ULPA filter, efficiency > 99.999% for particle size between 0.1 to 0.2 microns

  Illumination

≥ 1000 Lux

Fluorescent Lamp

28Wx2

UV

30Wx1

material

work area: 1.5mm 304 stainless steel, body: cold-rolled steel sheets with anti-bacteria powder

Net Weight

380 kg

gross Weight

400 kg

Shipping Dimensions, Maximum (W x D x H)

1570 x 950 x 2220 mm

Electrical

110/220V±10%/50-60HZ

Optional accessory

Armrest, Formalin fumigation sterilizer, infrared sterilizer, airflow tester

Standard Configuration

Base stand, drain valve, waterproof sockets, Remote control, Foot switch, UV lamp*2 and Fluorescent Lamp
