BIOBASE-BK 9870 Automatic Kjeldahl Analyzer Apparatus

Specifications

Automatic Kjeldahl Analyzer
1. UK Self-priming diaphragm pump
2.Titration precision: 0.5Ul/step
3.SIEMENS CPU control



Operating System



1. Operation system has 7.5 inches large color touch display screen, SIEMENS CPU control platform, and can be connected to wireless mouse.

2. It has Chinese display interface with perfect man-machine interaction function, and the operational process is easy to operate and understand.

3. Two operating modes, automatic analysis and manual analysis, can meet requirements of different experiments.

4. USB data communication interface, standard configuration, is convenient for users to inquire raw data.

5. Wireless mouse, standard configuration.



Executive system

It adopts self-priming diaphragm pump imported with original packing from British to feed liquid and thoroughly weeds out pneumatic diaphragm pump used by many domestic factories. Feeding liquid by self-priming pump can put liquid-feeding barrel under the operation floor which has advantages of effectively saving lab room, choosing large capacity liquid-feeding barrel, etc.









Model	BK9870	BK9870A
Working process	Adding quantitative sample dilution, alkali liquor and absorption liquid; automatically finishing distillation, titration, print and liquid-discharging.
Measurement range	0.1-240mgN
Measurement sample amount	Solid<6g liquid<16ml
Measurement time	4-8 minutes
Titration precision	2.0Ul/step	0.5Ul/step
Titration solution concentration	Direct titration samples with 4 titration concentrations of 0.1mol,0.5 mol and 1 mol
Titration system	High-precision plunger type titration system	High-precision peristaltic titration system
Executive standard	Comply with stipulations of AOAC, EPA, DIN, ISO AND GB
Repeatability precision	±0.5%
Recovery ratio	≥99.5%
Data storage	Effective storage space 2G
Print function	110mm line printer which can realize user selective print function
Power	1800w
Power supply	220v/50Hz
Requirement of cooling water	Under 25°C
Cooling water consumption	1.5L/min (Distillation process)
