Stepper Motor Drivers for 3 or 4 Axes Machines
US$ 30 - 80
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Shanghai, China
Brand Name:
UIROBOT
Model Number:
UIM24004
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
UIM Steppe Motor DriversUS$ 30 - 80MOQ: 1 Piece -
UIM Stepper Motor DriversUS$ 30 - 80MOQ: 10 Pieces
-
UIM 24008 Stepper Motor Driver-shanghai UI ROBOTUS$ 30 - 80MOQ: 1 Piece
-
UIM 24008 Step Motor Driver Pulse and Direction 02,04,08AUS$ 30 - 80MOQ: 1 Piece
-
UIM 24008 Stepper Motor DriverUS$ 30 - 80MOQ: 10 Pieces
Place of Origin
Shanghai, China
Brand Name
UIROBOT
Model Number
UIM24004
Motor Type
Stepper Motor
Specifications
Miniature Size 42.3mm*42.3mm*13.5mm NEMA size 17Wide range power supply 10-40VDC
stepper motor drivers for CNC machine
Stepper motor drivers for CNC machine
Miniature Size 42.3mm*42.3mm*13.5mm NEMA size 17
Integrally designed to fit onto stepper motors seamlessly, as well as work standalone.
Wide range power supply 10-40VDC, Max 4A per Phase settable output current, full, half, quarter and 16th Microstepping
Dual H-bridge with PWM constant current control
Enable/shutdown controllable
Opto-isolated inputs with common anode
Die-cast aluminium heat-sink enclosure
DIR, SPD, CUR, STP, Microsteppers
Idle Current Reduction
