Help Center1.5-4 Amps UIM 24004 Stepper Motor Driver (UIROBOT)
Related Products
-
the Smallest Integrated Stepper DriverUS$ 1 - 100MOQ: 1 Piece -
Step Motor Controllers With Micro Step UIM24002 24004 24008US$ 1 - 45MOQ: 5 Pieces
-
Integrated Miniature Step Controller With RS232 (UIM24104/24108)NegotiableMOQ: 5 Pieces
-
Stepper Driver for Bipolar or Uni-polar Stepper MotorsUS$ 1 - 100MOQ: 1 Piece
-
Stepper Motor Controller With Serial Port for Medical EquipmentUS$ 1 - 150MOQ: 1 Piece
UIM 24004 stepper motor driver
1.6-4A adjustable output current.
Miniature size 42.3mm*42.3mm*13.5mm
Integrally designed to mount onto stepping motors seamlessly, as well as work standalone
12-40VDC supply, Max 4A adjustable output current
1to16th Micro-stepping
Dual H-bridge with PWM constant current control
Enable/shutdown controllable
Opto-isolated inputs with common anode
Die-cast aluminium enclosure provides a rugged durable protection and improves the heat dissipation.
| Power Supply | Phase Current |
| 10-40V DC | 1.5-4 amps settable |
Bipolar constant current driver attributes
Features Drawbacks Applications
• Maximum motor utilisation and high efficiency.
• Maximum torque at low and high stepping rates.
• Low losses stand bye mode possible.
• 8-lead motors can be configured for 3 different operating currents.
• No snubbing circuits required and current turn off can be selected for fast (return to power supply) or slow.
• Highly integrated drivers available, second sourced drives also available.
• 8 power transistors needed to drive a motor.
• Problems with electrical noise and interference can occur.
• Power losses in current sensing resistors.
• For small and medium size motors highly integrated drivers are available.
• High speed and high power applications.
