Home > Industrial Equipment & Components > Ventilation Equipment > Blowers > Industrial Poultry Farm Greenhouse Ventilation Fan

Industrial Poultry Farm Greenhouse Ventilation Fan

Industrial Poultry Farm Greenhouse Ventilation Fan photo-1
Industrial Poultry Farm Greenhouse Ventilation Fan photo-2
Industrial Poultry Farm Greenhouse Ventilation Fan photo-3
Industrial Poultry Farm Greenhouse Ventilation Fan photo-4
Industrial Poultry Farm Greenhouse Ventilation Fan photo-5
Industrial Poultry Farm Greenhouse Ventilation Fan photo-6
US$ 142 - 142 MOQ: 10 Pieces
Key Specifications
Get Latest Price
Electric Current Type:
AC
Blade Material:
Stainless Steel
Mounting:
Wall Fan
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Electric Current Type AC
Blade Material Stainless Steel
Mounting Wall Fan
Place of Origin Shandong, China
Brand Name PengSheng
Model Number greenhouse ventilation fan
Power 1.1kw
Voltage 220V/380V
Air Volume 44400m3/h
Speed 1480r/min
Certification CCC, CE, Other, CCC, CE, ISO9001
After-sales Service Provided Overseas service center available

Industrial Poultry farm greenhouse ventilation fan

Product Description

Industrial Poultry farm greenhouse ventilation fan, exhaust fan price

    1, Frame:  frames are made of galvanized board, thickness 1.0mm, galvanizing layer 180g/square meter.or 275g/m^2 galvanized steel .



    2, Blade:  6 pieces, material 430/201 stainless steel, mirror face.or Aluminum alloy blades



    3, Impeller, casting aluminum alloy impeller.



    4, Bearing of impeller :permanently sealed bearing, size 633313.



    5, Venture: galvanized board, thickness 1.0mm.



    7, Inlet wind protecting net:  spraying paint steel wire, thickness 2.5mm.



    8, Electrical motor:  aluminum alloy frame motor, 380V/220/415V, 1.1KW/0.75KW(1.5HP/1HP), 50HZ/60HZ, 3PH/Single Phase, 4pole speed, 1410r/m, IP55, class F, efficiency 90%, top/foot mounted,



    9, Motor bearing, :national grade.



    10, Belt: V-belt and A-belt (Made-in-China and Japan brand Mitsuboshi).



    11, Shutters, galvanized board, 0.8 mm thickness while the middle piece thickness 1.0mm. Galvanizing layer ,120g/square meter.



    12, Opening system, two types.



    13, Rivets: aluminum alloy and stainless steel rivets.



    14, Cable: 1 meter long, strong robber wire.



    15, Warranty : 1 year for the whole machine.2 years for the motor.

Industrial Poultry farm greenhouse ventilation fanIndustrial Poultry farm greenhouse ventilation fan

FAQ

 Trade Information:

1.Trade Terms:EXW,FOB,CFR and CIF



2.Payment Terms:T/T,L/C



3.Payment Condition:30% deposit in advance,70% balance against B/L.



4.Delivery Time:15 days after the deposit.



5.Packing:by carton



6.Shipping:by sea/air/express delivery

 Trade progress:

Contact Way

If you can't find the datas you need, pls send us your performance requirements,

we will provide you customized design service in 8 hours.

       Skype           :qdpsdq.dong

      Mobile          :+86 13079292921

       My name     :Anthony Lu
