Specifications
800kva Deutz Diesel Generator Set1.Deutz diesel generator
2.low fuel consumption
3.high reliability and durabilit
4.CE
800kva Deutz Diesel Generator Set
Genor Power Deutz series diesel generator setd adopt DEUTZ TBD series low power diesel engine made by Sino-Germany Joint-Venture Company in China.The DEUTZ engines are 4-cycle,water cooled, 24DVC working voltage for conrol system,adopt circumvolve fuel fiter&oil filter cleaner, Dry air cleaner,compact structure,fine quality,reliable capability
| Model | GNRD640KW | |
| Rated Power | Rated power KW | 640 |
| Standby power KW | 700 | |
| 100%Unit Load | Oil consumption g/kwh | ≤0.08 |
| Fuel consumption g/kwh | ≤198 | |
| Current A | 1137A | |
| Diesel Engine | Model | TBD620L6 |
| Number of cylinder | 8 | |
| Discharge capacity(L) | 26.6 |
|
| Bore × stroke | 170X195 | |
| Alternator | Single bearing,brushless,self execution,Automatic pressure,H level Insulation,IP21-IP23 protection rank | |
| Generator Set | Configuration | High strength steel structure chassis,Integration assembly |
| Specification | 50/60HZ,1500/1800rpm,400V/230V,Power factor0.8,Three-phase four line | |
| Dimension L | 4650 | |
| Dimension W | 1716 | |
| Dimension H | 2316 | |
| Net Weight KG | 6450 | |
Genset Features:
1. Genuine Detuz diesel engine
2. Radiator 40°C max,fans are driven by belt, with safety guard
3. Original Leroy Somer, Stamford, Marathon, or ENGGA alternator
4. Choice of manual/auto and AMF control panels and protection systems
5. Digital auto-start panel
6. Anti Vibration Suspension Absorber
7. Dry type air filter, fuel filter, oil filter
8. 10-hour operation base tank
9. Mould case circuit breaker
10. 24V DC start motor and storage battery
11. 24V charge alternator
12. 24V batteries, rack and cable
13. Ripple flex exhaust pipe, exhaust siphon, flange, and muffler
14. Comply with ISO and CE standards.
15. All generator sets are gone through rigorous testing before being released to the market place, including 50% load, 75% load, 100% load , 110% load and all protection function (over speed stop, high water temperature, low oil pressure, battery charging fail, emergency stop)
General Technical Data
1. Frequency: 50 & 60Hz
2. Phase: 3 Phase 4 Wire & 1 Phase 2 Wire
3. Voltage: 120/207V,127/220V,220/380V, 230/400V, 240/415V, etc
4. Small volume, light weight, low noise, low fuel consumption, water cooling with water tank
5. Monitoring meters and control switches
6. Protection provided for short, over-current, over-speed, high water temperature and low oil pressure
Control Panel:
1. Manual/Automatic start & stop controller
2. Various Monitor Meter and Optional Switch
3. Remote control interface and Remote monitor/Remote Sense/Remote Meter (Optional)
4. MCCB for Short circuit & Overload (optional)
5. High water temperature alarm, Low oil pressure alarm, over speed alarm and other kind of alarm
