World Brand ! 10kw Air Cooled Diesel Generators

Name: World Brand ! 10kw Air Cooled Diesel Generators
Brand: Deutz
SKU: 140637792
Availability: InStock

US$ 8,999 - 11,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

Deutz

Model Number:

GNRD

Contact Supplier Request Quote Chat Now

Shenzhen Genor Power Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name Deutz

Model Number GNRD

Output Type AC Three Phase

Speed 1500rpm or 1800rpm

Frequency 50Hz or 60Hz

Rated Power 10KW

Rated Voltage 220V/380V, 230V/400V, 240V/415V

Rated Current 18A

Specifications

10kw Air Cooled Diesel Generators
1.Deutz Air Cooled Diesel Generator
2.Prime Power:10kw
3.Low Fuel Consumption
4.ISO9001

10kw Air Cooled Diesel Generators

Output Ratings
400/230V 50/60HZ
Model	GNRD10
Prime Power	Standby Power
12KVA	14KVA
10KW	11KW

Technical Data
Engine Model	Deutz F2L912
Alernator Model	Stamford PT044F
Number of Cylinders	L2
Cubic Capacity Litres	1.88
Bore/Stroke mm	100/120
Compression ratio:	17/1
Aspiration	Natural
Firing Order	1/2
Cooling Method	Air Cooling
Timing Mode	Mechanical adjusting speed
Frequency	50 Hz
Engine speed	1500 RPM
Gross Engine Power KW	16
BMEP KPA	680.8
Piston Speed m/sec	6
Total Radiated Heat l/hr	4.17
Exhaust Temperature °C	500
Total Capacity of Lube Oil	8
Combustion Air Flow m3/min	1.42
Exhaust Gas Flow m3/min	1.46
Size(mm)	1200850950
Weight(kg)	350

Standard Configuration
Engine	Mechanical speed regulator governor (ISO3046-A1, ISO8528-5-G2)
	Electronic control system voltage 12 V
	Oil bath air cleaner with pre-cleaner and dust collector
	Automatic belt tension unit
	V-belt break alarm device
	Shell type fuel filter and oil filter Dry air filter
Alternator	Brushless and self-excited
	Insulation class H
	Protection class IP22/IP23
	Electrical design as BS5000-99,IEC60034-1,VDE0530, NEMAMG-1.22
Control System	Deepsea,ComAP control panel
Control System	Antivibration steel plate shell, knock-down panel
Assembly	Genset base is made of high tensile steel plate with lifting hole
	Shock pad
	Flexible connection between genset and alternator
	Integrated base fuel tank(for 6hs full-load running
Exhaust System	Euipped with heavy industrial silencer ,reducing noise of 10db(A)
Cooling System	Normal running temperature ≤50°C(122°F)
Cooling System	Belt guard (only for generator set)
Air Switch	Below 160A: three-pole MCB
	Above 160A: three-pole MCCB
	Antivibration shell, active panel
	Output cable lead from the bottom of air switch
AVR	Voltage regulation from noload to full load <0.5%
AVR	Transient stability at sudden load and deload
Surface Treat	Electroplating for all metals
Surface Treat	Spraying high glaze polyurethane paint to make genset attractive and durable
Quality Standard	BS499, BS5000, BS5514, IEC60034, VDE0530,NEMAMG-1.22, ISO9001, ISO14001
Attached Files	Operation and maintenance manua
Attached Files	Electrical diagram
Warranty Period	One year or 1000 running hours after delivery date(subject to the prior time)

Optional Configuration
Fuel System	Extra large integrated
	Fuel transportation device
	Fuel-water separator
Silencing System	Residential silencer (about 25dB(A))
	Critical silencer (about 35dB(A))
	Common canopy genset
	Super canopy genset
Lub-System	Oil outlet valve
	High oil temperature alarm device
	Oil outlet pump
Alternator	Anti-freezing heater
	Auxiliary coil, permanent magnetic alternator
	AVR model R438,R448,R449
Control System	ZK6201,ZK6311
Control System	meters, mains charger, alarm indicator, stop button
ATS	double-power ATS panel
ATS	three-power ATS panel
Air Switch	3 pole upgrade to 4 pole
Trailer	Hydraulic brake device
	Adjustable chassis
	Fixed chassis
Accessories	Customer order
Tool kit	Customer order

Soundproof/Silent Box:

1. Excellent ventilation

2. Oil tank mounted on base frame for 12 Hours working

3. Highly Corrosion Resistant construction

4. Excellent Access for Maintenance

5. Security and Safety

6. 1m<80DBA / 7m<70DBA

Warranty policy

Guarantee for one year or 1000 hours whichever reach first from ex-factory date. During the guarantee period, Genor will provide the free easy-damageable spare parts of diesel engine caused by our quality of production or raw material. After expiration, Genor provides cost spare parts maintenance of gensets.
