Home > Products > weighing Scale > Truck weighing scale, easy installation, long-term stability
Truck weighing scale, easy installation, long-term stability
- 300 Set / Sets per Month
- Qingdao port
- T/T Credit Card PayPal
You May Like
Product Details
| Place of Origin | Shandong, China | Brand Name | Lubei | |
| Model Number | SCS-100t | Type | Truck Scale | |
| Power Supply | 110V/220V | Display Type | LCD/LED | |
| Rated Load | 100ton | Accuracy | 20kg |
Product Description
Truck weighing scale, easy installation, long-term stability
PRODUCT DESCRIPTION
SCS series electronic truck is a new generation of truck scale which depends on today’s domestic truck scale advantage. It’s gradually developed by our own technology and long period of overloading tests.
The main beam is sturdy Utype structure. The weighing platform panel selects Q235 flat and splices into the closed box-type structure, which is a reliable structure.
The welding technology, effectively ensure the flatness of such a large weighing platform, geometrical size and rational distribution of welding stress.
Welding platform design is standardizing, modularized, serialized, it can from to a variety of models freely, the system select high precision double shear beam or column weighing sensor, weighing indicator has rich features, strong storage and with a battery that can continue using when the power off, as well as a high precision, low temperature drift and stronger anti-interference stainless steel waterproof junction box, and signal shielded cable to make the measurements system multifunctional and reliable.
Structure function and features:
Modularization, digitization, standardization, serialization platform balance, multi-unit combination.
Automatic reset force transmission system
Can be matched with various indicators
Digital display gross weight, net weight, tare
Display dynamic, under load and overload situation
Digital filtering, clear tare automatically
Keyboard set/calibration
Vehicle NO. Tare storage, subitem accumulation, total accumulation
Data output/print automatically.
Specification
| Type of Product | SCS-20 | SCS-30 | SCS-50 | SCS-60 | SCS-80 | SCS-100 | SCS-120 | SCS-150 | SCS-200 |
| Max. Weighing capapcity (t) | 20 | 30 | 50 | 60 | 80 | 100 | 120 | 150 | 200 |
| Division(kg) | 5 | 5 | 10 | 10 | 20 | 20 | 20 | 50 | 50 |
| Sensor Cap. (t) | 10 | 20 | 20 | 20 | 30 | 30 | 30 | 40 | 40 |
| Platform size W*L(m) | Optimization Specification | ||||||||
| 2.2*5m | Y | ||||||||
| 2.5*6m | Y | Y | |||||||
| 3*7m | Y | ||||||||
| 3*8m | Y | Y | Y | ||||||
| 3*9m | Y | Y | Y |
| |||||
| 3*10m | Y | Y | Y | ||||||
| 3*12m | Y | Y | Y | Y | |||||
| 3*15m | Y | Y | Y | Y | |||||
| 3*16m | Y | Y | Y | Y | Y | ||||
| 3*18m | Y | Y | Y | Y | Y | Y | |||
| 3.2*18m | Y | Y | Y | Y | Y | ||||
| 3.4*18m | Y | Y | Y | Y | Y | ||||
| 3.2*20m | Y | Y | Y | Y | Y | ||||
| 3.4*20m | Y | Y | Y | Y | |||||
| 3.4*22m | Y | Y | Y | Y | |||||
Superior measurement performance, high accuracy, long-term stability, convenient installation and maintenance, make our truck scale widely used in
materials measurement in or not, inventory measurement, production monitoring and
data management and etc. It’s suitable for metallurgy, chemical industry, food, logistics
and other industries and is an ideal choice for weighing of lorries, trailers, containers,
dump trucks, agricultural vehicles and other overloading vehicles.
INDICATOR
LOAD CELL
COMPANY OVERVIEW
HOT PRODUCTS
Truck Scales Floor Scales Animal Scales
Cardboard Balers Plastic Balers Straw Balers
CONTACT US
| Shandong Lubei Weighing Scale Co.,Ltd & Dezhou Qunfeng Machinery Manufacturing Co.,Ltd | |
| TEL:+0086 13864061062 | No. 66, Ningde Road, Economic Development Zone, Ningjin County, Dezhou City, Shandong Province, China |
FAQ
1. Payment Method:
30% deposit T/T in advance, rest against the finished product photos.
100% in advance for sample order.
2. Delivery date:
According to produce schedule, generally, truck scale within 15 days;horizontal balers within 30 days.
3. MOQ:
For common products, we don't have MOQ limit, you can order any quantity you want.
If you need scales with your specification, logo, packing, etc, please negotiate with us.
4. Shipping:
a. International Express: DHL/TNT/FEDEX/UPS/EMS (For sample)
b. By air (For sample orders.)
c. By sea (15-45 days), port of loading: Qingdao,China
d. By domestic logistics to your forwarder. (2-7 days)
5. OEM Service:
We can produce scales with your logo, brand, packing, we can negociate details together.
6. Warranty:
All our scales are with 1 year warranty. During the warranty time, if any scales is out of service because of quality problem, we will send you spare parts and teach you how to repair until problem solved.
