Convenient machine sawdust pallet block making
---------------------------------------------------------------------------------------------------Brief Introduction of Wooden Pallet Block Making Machine
1.The production line consists of FIVE PARTs which is as follows:
Crusher,Dryer, Gluing Machine, Press Machine and Saw to cut up the block.
2. The raw material is sawdust, wood shavings, waste wood, used pallet etc.
NOTE: If the raw material size is not very big we do not suggest crushing first.
3. The pallet block's size can be made by customer's demands.
---------------------------------------------------------------------------------------------------
Main Parameter of Wooden Pallet Block Making Machine
| Items | Specifications | |
| Model No. | TY-PB150( Double head) | TY-PB100(Single head) |
| Block Size | Width:75-145mm; Height:75-145mm | |
| Power | 20.3KW | 13KW |
| Glue Consumption | 200-240Kg/m³ | 100-120Kg/m³ |
| Block density | 550-750Kg/m³ | |
| Production Capacity | 4m³/24h | 2m³/24h |
| Voltage | 380V, 50HZ | |
| Weight of the machine | 1500Kg | 1000Kg |
| Dimension of the machine | 5000*700*1300mm | 5000*600*1300mm |
Detailed Pictures of Wooden Pallet Block Making Machine
