Product Details
Condition: | New | Application: | Food, Beverage, Other, Food, Beverage, paste, sticky liquid | Packaging Type: | Cans, Bottles, Barrel |
Packaging Material: | Plastic, Metal, Glass | Automatic Grade: | Automatic | Driven Type: | Pneumatic |
Voltage: | 380v | Power: | 1.5kw | Place of Origin: | Henan, China |
Brand Name: | Thoyu | Model Number: | TYG-6 | Dimension(L*W*H): | 1850*850*2200mm |
Weight: | 650kg | Certification: | CE, ISO, BV | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
Paste,sauce filler machinesApply to viscosity materials
Automatic filling system
PLC control system, automatic
CE, ISO, BV.
Overview of Sauce, Paste and Sticky Liquid Filling Machine
This machine is specially made for all kinds of viscosity materials, such as detergent, honey, peanut butter, shampoo
etc. All the contacted part with the chemical oil is high quality stainless steel. The machine adopts piston pump
for filling. By adjusting the position pump, it can fill all of the bottles in one filling machine, with quick speed and
high precision.
TYG-6 heads Automatic volumetric linear filling machine is new generation utility product, developed from most
advancedtechnology to suit to market demand. The machine adopts piston pump, turning valve. Economic utility, low
plant cover, the machine is widely applied to sauce packing in the market of pharmaceutical, pesticides, chemicals,
foodstuff, cosmetic etc, meet to the requirement of GMP.
Features of Sauce, Paste and Sticky Liquid Filling Machine
1. Piston pump to measure quantity and fill, suitable for sauce, paste and sticky liquid, have high-precision.
2. Piston-ype measuring pump’s material is depend on filling material and adopts Silastic and tetrafluoroethylene
and other material, adopt ceram.
3. PLC control system, frequency control, high automatic-control
4. No bottle, no filling, automatic count.
5. Filling quantity is easy to adjust, adjust all pumps at the time or adjust respectively.
6. Adopt rotary valve.
7. Filling nozzle is drip-proof and anti-draw.
8. Under filling nozzle installed pneumatic water catcher.
9. The machine is suitable for different bottle, easy to adjust in short time.
10. Paste adopt double-layer heat preservation hopper (if needs hot filling) .
11. Meet GMP requirement.
Technical Parameter of Sauce, Paste and Sticky Liquid Filling Machine
Model | TYG-6 |
Filling nozzle | 6 |
volume | 340g (customize) |
capacity | 2,000-3,000B/H(for 500ml) |
Filling precision | ≤±1% |
Power supply | 380V 50/60Hz |
power | ≤2.2kw |
Air pressure | 0.4-0.6MPa |
