Home > Instruments & Meters > Optical Lens & Instrument > Telescope & Binoculars > High Resolution 384*288 Monocular Security Handheld Thermal Binoculars Night Vision Binoculars Long Distance Binoculars
High Resolution 384*288 Monocular Security Handheld Thermal Binoculars Night Vision Binoculars Long Distance Binoculars
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
DALI
Model Number:
S230
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Multifunctional CO2 Gas Detector Data Logger Temperature and Humidity Data LoggerUS$ 80 - 150MOQ: 10 Pieces -
Multifunctional CO2 Gas Monitor Humidity And Temperature Watches Gas Analyzer PriceUS$ 80 - 150MOQ: 10 Pieces
-
40M 131ft Digital Laser Distance Meter Rangefinder Measure LaserNegotiableMOQ: 1
-
60m Digital Laser Distance Meter Rangefinder OEM Laser Measurer Handheld Laser Measuring InstrumentUS$ 20 - 70MOQ: 1 Piece
-
S2 Laser Meter 60m OEM Laser Distance Meter Laser Rangefinder YellowUS$ 20 - 70MOQ: 1 Piece
Place of Origin
Zhejiang, China
Brand Name
DALI
Model Number
S230
High Resolution 384*288 Monocular Security Handheld Thermal Binoculars Night Vision Binoculars Long Distance Binoculars
384×288 uncooled FPA detector
1.8-meter drop resistance
One-hand operation, carrying light
Monocular OLED display
Good cost performance
Monocular OLED display
Good cost performance
| S230 infrared monoculars | Items | Technical Specification |
| Detector characteristics | Detector type | Un-cooled FPA micro-bolometer |
| Array size/format | 384x288 | |
| Image characteristics | Field of view/min focus distance | 29.9°×22.6°/0.1m |
| Spatial resolution(IFOV) | 1.36mrad | |
| Thermal sensitivity | ≤0.06°C@30°C | |
| Frame frequency | 50/60Hz | |
| Focus | manual | |
| Zoom | 2X | |
| Spectral range | 8-14um | |
| Image display | Display | 800x600 HD OLED monocular screen |
| Image Polarity | White/Black hot | |
| Image storage | Storage card | 2G Micro SD card |
| Storage mode | Manual | |
| File format | JPEG/MPEG4 | |
| Thermal image operation | Power key | On/Off switch |
| Brightness key | 5 optional cycle levels | |
| Zero key | Manual calibration | |
| Function key | Short press for E-zoon,long press for polarity shift | |
| Storage/Record key | Capture/record | |
| Power source | Battery type | Li-Ion, rechargeable |
| Battery operating time | 3 hours continuous operation | |
| Battery charging mode | Special designed,random charge | |
| Power saving | 10-15 V DC | |
| External power | <3.5W | |
| Environment | Operating temperature | -20°C-- +50°C |
| Storage temperature | -40°C-- +60°C | |
| Humidity | ≤90% non-condensing | |
| Encapsulation | IP67 | |
| Drop test | 1.8M,IEC68-2-32 | |
| Shock-resistant | 25G,IEC68-2-29 | |
| Anti-vibrated | 2G,IEC68-2-6 | |
| Physical characteristics | Weight | <900g |
| Dimension | 139x64x163mm | |
| Interface | Power interface | YES |
| Video output | YES | |
| USB | Image, measurement data transfer |
