Specifications
transportable small concrete mixers
Self-propelled feeder mixer wagon
Since the loading truck mixer
Self-loading mobile concrete mixers with loading concrete buckets. It can be equipped with digital aggregate weighing scale and water meter. Its size makes it reach places where concrete truck mixers can not reach.
Range of capacities: 2/ 2.5/ 3/ 4 m3
Concrete and materials’ dumpers 4 wheel drive with hydraulic tipping.
Range of capacities: from 600 liters up to 3000 liters& payload up to 7 tons
Technical parameters:
MIXING UNIT | Drum capacity 3.0 m3. Concrete output: 2.0 m3 per batch. |
PRODUCTIVITY | up to 4 batches per hour |
ENGINE | (or WEICHAI ANDcummins) |
TRANSMISSION | 4 wheels drive,2 wheels steering. |
SPEED | Working speed from 0 to 9 km/h, road transfer from 0 to 20 km/h. |
DRIVING SEAT | Front cab on side of loading shovel. ROPS-FOPS type complete with double closing door. |
HYDRAULIC SYSTEM | Three circuits. 2 variable outlet pumps for hydrostatic transmission and drum rotation. |
JOYMIX | All hydraulic functions of shovel controlled by a single - fully servo controlled Joystick. |
LOADING SHOVEL | Capacity 400 liters, complete with hydraulic opening gate. |
WATER SYSTEM: | Self-contained. Hydraulic driven water pump, High pressure water pump & washing gun(on request). |
BRAKES: | Oil bath disc brakes inside differential axles. Twin indipendent circuits. Negative hydraulic parking brake. |
TYRES | 20.5-16/70 |
ELECTRIC SYSTEM | 24 Volt. 120 Ah battery for electric starter and road lighting. Safety battery cut-off. |
TANKS | Water: 1x300 liters. Diesel: 100 liters. Hydraulic oil: 125 liters. |
CHASSIS | Steel profile specially engineered for off-road operations. |
WEIGHT | About Kg.5500, equally distributed on both axles |
OVERALL DIMENSIONS | Long: 6.5M Width 2.16M High: 2.8M |
SAFETY | Machine equipped with checking and block valves for maximum safety of the operator. |
Can produce according to customer requirements
