From 1mm to 50mm Thickness SBR Rubber Sheet Plate

Specifications

1. Thickness: 1mm-50mm
2. Width: 0.9m-2m
3. Length: according to required
4. Surface Finished: smooth or cloth impression

SBR Rubber Sheet

Material: Styrene Butadiene-Buna S– GRS



Features:

1. Better wear-resistant

2. Resistance to Chemicals; good resistance to many inorganic chemical products.

3. They do not have the same resilience as Natural Rubber.

Specification:

SBR RUBBER SHEET	Code:BS-SBR
Tensile strength	3-10Mpa
Hardness	50-80Shore A
Elongation	200%--450%
Specific Gravity	1.40-1.60g/cm3
Tear strength	12--40 N/mm
Working temperature	-25/70°C
thickness	From 1 to 50mm
Width	From 0.90 to 2.0m
Executable standard	BS1154-Z60, ASTM
Surface Finished	Smooth or cloth impression



Recommended Uses:

popular flange gasket material for hot or cold water, air and steam. All mating flanges wherever a quality rubber sheet is required. Remarks: Deforms to uneven flanges.



Properties:
• Its general properties are similar to those of Natural Rubber, but it is more resistant to ageing and temperature, and like Natural Rubber, these properties can be improved further by careful compounding.

• Temperature range: -50º C to +70º C.

• Due to its unsaturated molecular structure SBR materials tend to have only moderate resistance to tearing, ozone and general weathering. They do not have the same resilience as Natural Rubber.

• Resistance to Chemicals; good resistance to many inorganic chemical products
