Specifications
1. Thickness: 1mm-50mm2. Width: 0.9m-2m
3. Surface Finished: smooth or cloth impression
4) QC: ISO9002
Rubber Sheet
Features:
1. Better wear-resistant
2. Resistance to Chemicals; good resistance to many inorganic chemical products.
3. They do not have the same resilience as Natural Rubber.
Specification:
Industrial Purpose Rubber Sheet | |||
SBR, Neoprene, Nitrile, EPDM, Silicone, Viton, Butyl, Insulation, Antistatic, Abrasion Resistance, Fire Resistance, Oil-resistance… | |||
SBR |
Working Temperature |
-30°C-80°C |
|
Tensile strength |
2-8mpa |
||
Hardness |
50-80 Duro |
||
NBR |
|
General Grade |
High Grade |
Material Selection |
SBR/NBR |
Nitrile |
|
Working Temperature |
-30°C-80°C |
-30°C-110°C |
|
Tensile strength |
3-8mpa |
||
Hardness |
50-80 Duro |
||
CR |
|
General Grade |
High Grade |
Material Selection |
SBR/CR |
Neoprene |
|
Working Temperature |
-30°C-80°C |
-30°C-110°C |
|
Tensile strength |
3-8mpa |
||
Hardness |
50-80 Duro |
||
EPDM |
|
General Grade |
High Grade |
Material Selection |
SBR/EPDM |
EPDM |
|
Working Temperature |
-30°C-80°C |
-30°C-110°C |
|
Tensile strength |
3-8mpa |
||
Hardness |
50-80 Duro |
||
Silicone |
Working Temperature |
-50°C-220°C |
|
Tensile strength |
6-8mpa |
||
Hardness |
60-70 Duro |
||
Viton |
Working Temperature |
-50°C-220°C |
|
Tensile strength |
6-8mpa |
||
Hardness |
70+/-5 Duro |
||
Insulation |
Polymer Content |
100% SBR |
|
Working Temperature |
-30°C-100°C |
||
Proof Voltage |
15KV-50KV |
||
Color |
Black, Grey |
||
Surface |
Smooth/ fine rib |
||
Antistatic/ESD |
Material |
NBR/SBR |
|
Working Temperature |
-30°C-100°C |
||
Top Layer |
107-109Ω |
||
Bottom Layer |
103-105Ω |
||
Color |
Green+black |
||
SBR RUBBER SHEET |
Code:BS-SBR |
Tensile strength |
3-10Mpa |
Hardness |
50-80Shore A |
Elongation |
200%--450% |
Specific Gravity |
1.40-1.60g/cm3 |
Tear strength |
12--40 N/mm |
Working temperature |
-25/70°C |
thickness |
From 1 to 50mm |
Width |
From 0.90 to 2.0m |
Executable standard |
BS1154-Z60, ASTM |
Surface Finished |
Smooth or cloth impression |
Description:
Produced by drum type vulcanizing machine and plate vulcanizing machine, finished through one or several processes, fresh luster and no pollutions ,material is SBR rubber and NR.
Properties:
• Its general properties are similar to those of Natural Rubber, but it is more resistant to ageing and temperature, and like Natural Rubber, these properties can be improved further by careful compounding.
• Temperature range: -50º C to +70º C.
• Due to its unsaturated molecular structure SBR materials tend to have only moderate resistance to tearing, ozone and general weathering. They do not have the same resilience as Natural Rubber.
• Resistance to Chemicals; good resistance to many inorganic chemical products
