Specifications
Reinforcing Mesh1.Meterial:low carbon steel wire
2.Diameter:5mm~20mm
3.Certification:ISO/SGS/BV
4.Delivery Time:1 day
Reinforcement Welded Wire Mesh
Square Reinforcing Mesh
This general purpose mesh is used for reinforcing flat concrete elements such as flooring, footpaths slabs and walls etc. Square mesh is manufactured from L grade ribbed wires (D500L) that are welded together with equal spacing in both directions to form square apertures.
Square mesh sheets are supplied in 6m x 2.4m with side lap wires to minimize the laps between sheets on large areas.
Products listing
Ref No. |
Std Unit |
Longitudinal |
Edge Wires mm |
Cross Wires mm |
Mass Kg |
SL81 (F81) |
Sheet |
7.6 @ 100 |
7.60 @ 100 |
7.60 @ 100 |
105 |
SL102 (F102) |
Sheet |
9.5 @ 200 |
6.75 @ 100 |
9.50 @ 200 |
80 |
SL92 (F92) |
Sheet |
8.6 @ 200 |
6 @ 100 |
8.60 @ 200 |
66 |
SL82 (F82) |
Sheet |
7.6 @ 200 |
5.37 @ 100 |
7.60 @ 200 |
52 |
SL72 (F72) |
Sheet |
6.75 @ 200 |
4.77 @ 100 |
6.75 @ 200 |
41 |
SL62 (F62) |
Sheet |
6 @ 200 |
4.77 @ 100 |
6 @ 200 |
33 |
SL52 (F52) |
Sheet |
4.77 @ 200 |
4.77 @ 100 |
4.77 @ 200 |
21 |
Specifications:
Product name |
Reinforcement nonwoven waterproof rolls with polyester fiber |
Material |
100% polyester (polyester staple fiber) |
Weight |
NonNational standard:120gsm, 140gsm, 160gsm, 180gsm, 200gsm, 220gsm, National standard:220gsm,250gsm, 330gsm,450gsm |
Width |
1.02m or according to customer's requirement |
Characteristic |
Better tensility, elongation and hot shrinkage, high strength for preventing thrust, anticorrosion and anti-aging |
Color |
white (standard) , green,etc; |
Package |
Shrank wrapped each roll, then put in pallet |
Usage |
For SBS and APP bitumen waterproofing membrane, underground bridge's surface project and antiseptic conduct of the buildings' base...... |
Delivery time |
Within 15days after receiving the prepayment |
Factors for quotation
1)wire dia of the mesh
2)weight of the pole,measurement of the pole(clip number,screw number)
3)dimension of the mesh
4)dimension fo the whole fence (including the embeded parts)
5)the processing of the surface(galvanized or PVC-coated)
6)quantity for your inquiry ( sets)
Some pictures for reference:
