Reflective Glass Beads for Road Marking Paint Tiny Glass Microspheres
GLASS BEADS HAVE 3 TYPES:
1. DROP ON FOR THERMOPLASTIC PAINT
2. PRE MIXED FOR THERMOPLASTIC PAINT
3. DROP ON FOR COLD SPRAYING ROAD MARKING PAINT
Function of Glass Beads for Road Marking Paint
Improve the road marking line contrary reflection function. When driving at night, the lamp shines on the marking line with glass bead in it, the ray of lamp is reflected back parallely. So the driver can look at the road clearly and drive safely at night.
Specifications of Glass beads for road marking paint
| Type | Glass bead granul diametre limit(μm) | Glass bead quality percentage(%) |
| BS6088A |
>1180 | 0~3 |
| 1180~850 | 5~20 | |
| 850~425 | 65~95 | |
| <425 | 0~10 | |
| BS6088B | >850 | 0~5 |
| 850~600 | 5~20 | |
| 600~300 | 30~75 | |
| 300~180 | 10~30 | |
| <180 | 0~15 |
The main products:
1. BS6088A and BS6088B size distribution according to British Standard BS6088.
Table 1 Glass bead Size Distribution (BS6088A/B International Standard)
2.Products according to international standard include:BS6088,KS and AASHTO,EN1423 etc.
3.You can choose different size glass bead between 50μm-1180μm according to different funcition.
Technical references
Appearance: Colourless and transparent ball, no visible bubbles and impurity.
Spherical beads:≥80%(600< Sieve size< 850um,spherical beads≥75%)
Density:2.4-2.6g/cm3
Refractive index:Nd≥1.50
Glass bead composition:The glass bead is made of sodium and calcium. SiO2>68%
Package:
1.Using double-deck package, the inner is polythene film and its thickness is not less than 0.5mm,the outer is plastic woven bag to prevent leak or damp. The net weight of each bag is 25±0.2kg.
2.Using double-deck package, the inner is polythene fim and its thickness is not less than 0.5mm, the outer is plastic woven bag to prevent leak or damp. The net weight of each is 1000±8kg.
Packaging & Delivery of road marking paint
Packaging Details: |
25KG/BAG |
Delivery Detail: |
3-5 days after payment |
We also supply thermoplastic road marking machines:
Road marking line removal machine
OR-XRM-01
Our Business Scope:
Road Marking Paint
Road Marking Glass Bead for Reflective Paint
Thermoplastic Pre-heaters
Thermoplastic Road Marking Machine
Cold-Painting Road Marking Machine
Zebra Crossing Marking Machine
Self-Propelled Road Marking Machine
Hand-Push Road Marking Machine
Road Marking Remover
Traffic Safety Products
Our factory & Certification
Zhengzhou Allraise Machinery Company Ltd have been designing, developing, manufacturing and marketing Machinery for more than 10 years. After these years of development, we have high quality professional teams, skillful talents, strong technical force, strong and independent research and development capabilities, advanced production equipment and a perfect after-sales service system. So choose us, equaling to choose the competitive price and stable quality both.
Don't worry your TT payment,we do make the shipment as S/C,B/L for your reference!
Please feel free to contact me if any interest!
