9Hp Concrete Vibrating Truss Screed/ Screed concrete vibrator/ Concrete screed
Concrete truss screed is used for concrete road surface lifting pulp, vibrating, leveling.
It is a new equipment for roads, squares and modern factory building. And it is a traditional paver upgrading products. Can choose gasoline engine or electromotor.
Specification of concrete screed machines
| Model | OR-XZP-55 | OR-XZP-90 | OR-XZP-130 |
| Engine Model | HONDA GX160 | HONDA GX270 | HONDA GX390 |
| Power | 5.5HP/4.0kw | 9HP/5.5kw | 13.0HP/7.5kw |
| Working Width | 4m-7m | 8m-12m | 12m-16m |
| Working Depth | 260mm | 260mm | 260mm |
| Vibration Frequency | 70Hz | 70Hz | 70Hz |
| Standard Knot | 1000/2000mm | 1000/2000mm | 1000/2000mm |
| Fuel Tank Capacity | 3.6L | 6L | 6.5L |
| The Amount of Lubricating Oil | 0.6L | 1.1L | 1.1L |
| The Amount of Fuel Consumption | 313g/kWh | 313g/kWh | 313g/kWh |
Features of concrete screed machines
1. HONDA power ( or famous electric) brand quality assurance, superior performance, easy to start.
2. Truss screeds baseplate select could rolled sheet, wear and corrosion resistance.
3. The overall frame adopts full steel structure, strong earthquake, won't be hard deformation.
4. Removable and free combination design, greatly reduces the maintenance and transportation cost.
5. The whole meters can fast joint together, reduce the cost.
We also supply Concrete laser screed
Surface Finishing Screed
Packaging & Delivery of Concrete screed machine
Packaging Details: |
wooden case or what is required. |
Delivery Detail: |
6-15 days after payment |
Our factory & Certification
Zhengzhou Allraise Machinery Company Ltd have been designing, developing, manufacturing and marketing Machinery for more than 10 years. After these years of development, we have high quality professional teams, skillful talents, strong technical force, strong and independent research and development capabilities, advanced production equipment and a perfect after-sales service system. So choose us, equaling to choose the competitive price and stable quality both.
Don't worry your TT payment,we do make the shipment as S/C,B/L for your reference!
Please feel free to contact me if any interest!
Zhengzhou Allraise Co., Ltd.
Email: sophiayang at
Web: www.allraising.en.china.cn
