Portable magnetic stripe card reader MCR01 provides superior reading performance for your mobile device

Specifications

1.Slim size: light and slim size for high portability.
2.Read card information with a single swipe in either direction

  MCR01 3.5mm audio jack Mobile Swipe Card Reader Best Secure Card Reader



It is an encrypted magnetic stripe reader that works with various mobile devices. It reads up to 2 tracks of information with a single swipe in either direction, providing superior reading performance for your mobile device.  Customize appearance and color is available





1. Slim size: light and slim size for high portability

2. Reduce investment: The user may use own mobile phone to complete the transaction. No need to invest for the heavier POS or ePOS

3. High security: Data is encrypted before transmitted to the mobile phone. Avoid the possibility of being stolen by trojan horses.

4. High reliability: Embedded professional decoder IC speed up the decoding. High swiping performance

5. Ultra low power consumption: Power up by button cell. Peak operating current < 1mA, which could be the lowest power consumption in the similar products.

6. High compatibility: Support bidirectional communication between phone and device. Compatible for domestic and imported mobile phones. Can support 90% or above smart phones.





Features:

• Plugs into audio headphone jack – no cables
• Mechanical design allows easy and reliable card swipe
• No external power supply required
• Superior magstripe reader performance
• Bi-directional card reading
• Reads up to three tracks of card data
• Data is encrypted for end-to-end security using TDES, DUKPT





Specification:





Model	MS612 (Dual tracks: 1, 2 track) MS623 (Dual tracks: 2,3 track)
Power Source	Power up by embedded button cell (Depend on customer: Can be powered up by Audio jack of Mobile phone)
Connection to mobile	Plug-in 4 pins 3.5mm audio jack
Cards	Magnetic card. e.g. debit cards, membership cards
Decoding format	Build-in Hardware decoder
Battery life	20,000 times for normal swiping
Battery standby time	5 years
Swiping speed	3 - 70 IPS (7.6 - 177.8 cm/s)
Swiping direction	Dual direction
Swiping time	500,000 times
Encryption	Swiped data encrypted before sent to mobile phone
Encryption method	Optional: 3DES (TDES)/AES. Support FIXED KEY or DUKPT key management
Encryption spped	< 200ms (complete data encryption from all tracks)
Supporting system	iOS, Android system
Peak current	< 1mA
Operating Temperature	-20'C to 70'C
Measurement	41.7mm x 30mm x 13.7mm
Weight	18g
