Specifications
1.durable flexible encapsulation and small size2.frequency is 866-868MHZ and 902-928MHZ.
3.62.5 x9.4x3.6mm
4.IP68 protection
With its durable flexible encapsulation and small size, LQ210 tags are ideally suited to tool tracking and industrial asset tracking applications including attachment to:
- Tools including wrenches and ratchet tools.
- .
- Field IT assets.
RF Specifications | |
Protocol | EPC Class 1 Gen2 |
Frequency Range (MHz) | 866-868 (EU) 902-928(US) |
Read Range (Fixed reader) | 1.Up to 3m (9.8ft) |
Read Range (Handheld reader) | Up to 1.8m (6ft) |
Material Compatibility | Optimized for Metal substrates |
IC Type (chip) | Alien H3 |
Memory
| EPC - 96bit User - 512bits TID - 64bits |
Note 1. Quoted performance achieved using standard testing methodology. Read range will vary with Reader hardware and output power. 2. EPC and User memory are reprogrammable, TID is locked at point of manufacture | |
Physical Specifications | |
Material | Durable Thermoplastic Material |
Size (mm) | 62.5 x9.4x3.6mm/2.46 x 0.37 x 0.14in |
Weight | 2.1g |
Environmental Specifications | |
Operating Temperature | –40 ° to +85 °C |
Long term Max Temperature | exposure - (days, weeks, years) +105 °C |
Short term Max Temperature | exposure - (minutes, hours) +105 °C |
IP Rating | IP68 |
Shock and Vibration | MIL STD 810-F |
Impact | 10kg from 1m |
Attachment | Industrial foam tape (std) |
