Rfid Library Paper Label

US$ 0.16 - 0.41 MOQ: 200 Pieces

Key Specifications

Brand Name:

HCT

Model Number:

HCT-LT-22400

Hongchangtag Tech-Sci Development Inc.

Payment & Shipping

Payment Methods:

Port of Shipment:

Beijing or HK

Delivery Detail:

Delivery time depends on order quantity.

Brand Name HCT

Model Number HCT-LT-22400

Specifications

1.frequency 13.56Mhz
2.NXP I-CODE SLI chip,
3.support ISO15639
4.Reading range 1-5cm
5.adhesive tags,rfid tag for books

1. ISO/IEC 15693

2. Frequency 13.56MHZ

3.1024 bit User memory

4.chip NXP I-CODE SLI

5.Data transfer Rate 53Kbit/s

RF Features
Operated Frequencies				13.56MHz
Mode Of Operated				Passive(battery free)

Electrical Characteristics
Protocol				ISO/IEC 15693
User Memory				1024 bit

Inlay Material
Antenna				AL,15μm±3μm
HF IC				Silicon,150μm±10μm
Substrate				PET,38μm±5μm

ESD&Inlay Handling
Human Body Model				1.5KV
Charged Device Mode				1.5KV

Label Material
Surface Material				White coated paper,80g/mm
Adhesive				Acrylic emulsion,25μm±3μm
Release Paper				White glassine paper,60g/mm

Label Specification
Label Size(CD×MD)				50mm×50mm
Label Pitch				64mm±0.5mm
Liner Width				60mm±0.5mm
Max Units Per Roll				5,000pcs

Environmental Specification
Shelf Life				5 Years
Recommended Storage Condition				-25°C to +50°C 20% to 90%RH

Operating Temp				-40°C to +65°C

Item	NO.	Dimensions
Antenna length	1	47.0±0.05mm
Antenna width	2	47.0±0.05mm
Label length	3	50.0±0.1mm
Label width	4	50.0±0.1mm
Gap between two labels	5	14.0±1.0mm
Label edge to release paper edge(left)	6	5.0±1.0mm
Label edge to release paper edge(right)	7	5.0±1.0mm
Release paper width	8	60.0±0.5mm
Radius of label corner	9	3.0±0.1mm
Core inner diameter	10	3 inch(76.2±1.0mm)
Roll outer diameter	11	≤12 inch(305mm)
