Home > Electrical & Electronics > Smart Card & Card Reader > IC Card > Printable HF NFC Epoxy Tag Accept QR Code Printing and URL Encoding

Printable HF NFC Epoxy Tag Accept QR Code Printing and URL Encoding

Printable HF NFC Epoxy Tag Accept QR Code Printing and URL Encoding thumbnail-1
Printable HF NFC Epoxy Tag Accept QR Code Printing and URL Encoding thumbnail-2
Printable HF NFC Epoxy Tag Accept QR Code Printing and URL Encoding photo-1
Printable HF NFC Epoxy Tag Accept QR Code Printing and URL Encoding photo-2
US$ 0.05 - 0.85 MOQ: 200 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
OEM
Model Number:
NFC Tag-J-0001
Contact Supplier Request Quote Chat Now
Shenzhen Card Cube Smart Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name OEM
Model Number NFC Tag-J-0001
Associated Brands

Product Details

HF NFC Epoxy Tag

Physical Features

Material

Epoxy/PVC/PET/ABS etc.

Physical type

Epoxy nfc tag

Common Dimensions(mm)

Round

28,30,38,50mm or customized

Rectangle

25*25,30*30,30*25mm or customized

Printing

Full Color Printed as custom artwork

Technical Specifications

Frequency

13.56Mhz





Standards

ISO14443A





Common Chips

NTAG203,Ntag213,Ntag215,Ntag216,Topza512

FREE ENGINEER ADVICES

IF CONFUSED





Ultralight, Ultralight C





classic 1k (S50)





4k(S70)





DESFire 4k





FM11R08(China Fudan)





Reading distance

Up to 10CM, depends on Phone Model.





Rewriting Protection

Read-Only or Rewritable as requested





UID

Hex or Decimal





Applications

Advertisements

Smart Posters





NFC Business Cards, etc.





Mobile Payment

e-ticket





Membership value storage card, etc.





Access Control

Library, office





Apartment door management, etc.





Other filed

Book management, dry washing, etc.







 Features of NTAG213/215/216

 NFC Forum Type 2 Tag compliant IC with 144/504/888 bytes



user memory



The RF-interface is based on the ISO/IEC 14443 Type A standard



  •  Contactless transmission of data and supply energy
  •  Operating frequency of 13.56 MHz
  •  Data transfer of 106 kbit/s
  •  Data integrity of 16-bit CRC, parity, bit coding, bit counting
  •  Operating distance up to 100 mm (depending on various parameters as e.g. field
  • strength and antenna geometry)
  •  7-byte serial number (cascade level 2 according to ISO/IEC 14443-3)
  •  UID ASCII mirror for automatic serialization of NDEF messages
  •  Automatic NFC counter triggered at read command
  •  NFC counter ASCII mirror for automatic adding the NFC counter value to the NDEF message
  •  Fast read command
  •  True anticollision
  •  50 pF input capacitance

 EEPROM

  •  180, 540 or 924 bytes organized in 45, 135 or 231 pages with 4 bytes per page
  •  144, 504 or 888 bytes freely available user Read/Write area (36, 126 or 222 pages)
  •  4 bytes initialized capability container with one time programmable access bits
  •  Field programmable read-only locking function per page for the first 16 pages
  •  Field programmable read-only locking function above the first 16 pages per double
  • page for NTAG213 or per 16 pages for NTAG215 and NTAG216
  •  Configurable password protection with optional limit of unsuccessful attempts
  •  Anti-tearing support for capability container (CC) and lock bits
  •  ECC supported originality check
  •  Data retention time of 10 years
  •  Write endurance 100.000 cycles

Related products

Printable HF NFC Epoxy Tag Accept QR Code Printing and URL Encoding



Printable HF NFC Epoxy Tag Accept QR Code Printing and URL EncodingPrintable HF NFC Epoxy Tag Accept QR Code Printing and URL Encoding



Available Mold for NFC Tag (Size:MM)

Printable HF NFC Epoxy Tag Accept QR Code Printing and URL EncodingPrintable HF NFC Epoxy Tag Accept QR Code Printing and URL Encoding







Printable HF NFC Epoxy Tag Accept QR Code Printing and URL Encoding

 Packaging

100pcs/bag, 1000pcs/carton,   carton size:  20.5*23*17 CM

2000pcs/carton, carton size: 48*23*14 CM.

or customized

Payment Terms &  Shipment

Payment: L/C, T/T, Western Union, MoneyGram,PayPal; 50% deposits; 50% balance before delivery.

Shipment

1. FedEx/DHL/UPS/TNT for samples, Door-to-Door;



2. By Air or by Sea for batch goods, for FCL; Airport/ Port receiving;



3. Customers specifying freight forwarders or negotiable shipping methods!



4. Delivery Time: 3-7 days for samples; 7-9 working days for batch goods.

Contact

Telephone: 86-755- 89894425
Address : 4&7/F, Building E, Longjing Industrial Park, Bantian Street, Longgang District, Shenzhen, China
Zip: 518129
