UHF Alien H3 18000-6C 860-960MHz Transparent Dry Inlay

UHF Alien H3 18000-6C 860-960MHz Transparent Dry Inlay thumbnail-1
UHF Alien H3 18000-6C 860-960MHz Transparent Dry Inlay thumbnail-2
UHF Alien H3 18000-6C 860-960MHz Transparent Dry Inlay thumbnail-3
UHF Alien H3 18000-6C 860-960MHz Transparent Dry Inlay photo-1
UHF Alien H3 18000-6C 860-960MHz Transparent Dry Inlay photo-2
UHF Alien H3 18000-6C 860-960MHz Transparent Dry Inlay photo-3
US$ 0.025 - 0.6 MOQ: 200 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
OEM
Model Number:
NFC Sticker-J-0014
Contact Supplier Request Quote Chat Now
Shenzhen Card Cube Smart Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name OEM
Model Number NFC Sticker-J-0014

UHF Alien H3 18000-6C 860-960MHz  Transparent Dry Inlay
UHF Alien H3 18000-6C 860-960MHz Transparent Dry Inlay

Product Description

Features of Alien H3

  • › Meets EPC global Gen2 (V 1.2.0) as well as
  • ISO/IEC 18000-6C
  • › Worldwide operation in the RFID UHF bands
  • (860-960 MHz)
  • › 800-Bits of Nonvolatile Memory
  • › 96-EPC Bits, extensible to 480 Bits
  • › 512 User Bits
  • › 64 Bit Unique TID
  • › 32 Bit Access and 32 bit Kill Passwords
  • › Pre-Programmed with a unique, unalterable 64-bit
  • serial number
  • › User Memory can be Block Perma-Locked as well as
  • read password protected in 64 Bit Blocks
  • › Supports all Mandatory and Optional Commands
  • including Item Level Commands
  • › Custom Commands for high speed programming;
  • 30 tags per second for the 96-bit EPC number
  • › Low power operation for both read and program
  • › Exceptional operating range, up to 10m with
  • appropriate antenna

Applications

  • › Supply Chain Management
  • › Distribution Logistics
  • › Product Authentication
  • › Asset Inventory and Tracking
  • › Baggage Handling and Tracking
  • › Item Level Tagging

 ♦Pictures of NFC tag



 UHF Alien H3 18000-6C 860-960MHz Transparent Dry Inlay



UHF Alien H3 18000-6C 860-960MHz Transparent Dry InlayUHF Alien H3 18000-6C 860-960MHz Transparent Dry Inlay



 Applications

  •  Smart advertisement
  •  Goods and device authentication
  •  Call request
  •  SMS
  •  Call to action
  •  Voucher and coupons
  •  Bluetooth or Wi-Fi pairing
  •  Connection handover
  •  Product authentication
  •  Mobile companion tags
  •  Electronic shelf labels
  •  Business cards

Product Details

UHF Alien H3 18000-6C 860-960MHz Transparent Dry Inlay

Material:

 Paper, PVC, PET, etc.

Size:

80*16MM, 62*17MM, 90*16MM, 70*18MM, etc.

Thickness:

0.2~0.8mm

Minimum QTY:

200pcs

Available crafts:

Offset Printing, Digital Printing, etc.



Chip Available:



 UHF Chip: Alien H3, Ucode Gen2

 HF Chip: 1K S50 / 4K S70 / Ultralight/ NTAG203/213/215/216
 ICODE SLI-L(512 bit) / ICODE SLI(1024 bit) / ICODE SLI-S(2048 bit)
 EV1 4K

 EV1 8K
Tag-it HF-1 Plus (TI2048, TI 2K)
 1K-Compatible: FM11RF08(F08) / MF Classic 1k

4K-Compatible: FM11RF32 / MF Classic 4k

 plus S 2K/ S 4K

Plus X 2K/ X 4K

Applications:

Enterprises, bank, traffic, insurance, super marketing, parking, school, library management .access control ect.



Price terms:

We accept  EXW/ FOB/CIF/C&Fprice.
Payment term: pay by  L/C, T/T, Western Union, MoneyGram, or PayPal, . 50% deposit of the total payment before bulk production.



Lead time:

7-9 woking days after the receipt of 50% deposit of the total payment (below 50000 pcs.)



Delivery way:

By express ,by sea or air



Package details:

1000pcs/roll, 2000pcs/roll, customize; 10roll/carton,  carton size:  54*36*26 CM
Or 100pcs packed in one ploybag,  1000pcs/ carton, carton size:  30*23*25 CM



Sample Availability:

Free samples are available upon request.









 ♦Packing & Shipping

UHF Alien H3 18000-6C 860-960MHz Transparent Dry Inlay


1. FedEx/DHL/UPS/TNT for samples, Door-to-Door.



2. By bus,ferry and other transportation means.



3. Customers specifying freight forwarders or negotiable shipping methods!



4. Delivery Time: 3-7 working days for samples; 7-9 working days for batch goods.
