Plastic RFID Card with Ultralight EV1 Chip
♦Products Detail
| Material | Antenna | Copper Coin |
| Chip | COB | |
| Card | PVC | |
| Size | 85.5mm*54mm*0.85mm | |
| Chipset | Ultralight EV1 | |
| Frequency | 13.56MHz | |
| RF Interface | ISO14443A | |
| User Memory | 512 bit | |
| Read and Write | Yes | |
| Surface | Offset Printing | |
| Application | Public transportation; |
|
♦Embedded Chips Available
HF Frequency 13.56MHz Chips
| Chip | NTAG213/203 | NTAG216 | Ultralight/Ultralight C | I Code Sli/Sli-X | S50/F08 | Desfire EV1 D21/D41/D81 | S70/FM32 |
| RF Interface | ISO14443A | ISO14443A | ISO14443A | ISO15693 | ISO14443A | ISO14443A | ISO14443A |
| Memory | 144 Byte | 888 Byte | 512 Bit/192 Byte | 1024 Bit | 1k Byte | 2K/4k/8K Byte | 4K Byte |
| Write Endurance | 100.000 cycles | 100.000 cycles |
100.000 cycles |
100.000 cycles | 100.000 cycles |
100.000 cycles |
100.000 cycles |
| Data Retention Time | 10 Years | 10 Years | 10 Years | 10 Years | 10 Years | 10 Years | 10 Years |
| Operating Distance | Up to 10cm | Up to 10cm | Up to 10cm | Up to 10cm | Up to 10cm | Up to 10cm |
Up to 10cm |
|
Other Chips: Plus S2k/S4k, SLE66R35, S20,etc | |||||||
LF Frequency 125KHz Chips
| Chip | TK4100 | EM4100/4200 | EM4305 | T5577 |
| Memory | 64 Bit | 64 Bit | 512 Bit | 363 Bit |
| Reprogrammable | No | No | Yes | Yes |
| Write Endurance | 100.000 cycles | 100.000 cycles | 100.000 cycles | 100.000 cycles |
| Data Retention Time | 10 Years | 10 Years | 10 Years | 10 Years |
| Operating Distance | Up to 10cm | Up to 10cm |
Up to 10cm | Up to 10cm |
Other Chips: HitagS 256, Hitag 1 | ||||
UHF Chips
Chip |
RF Interface |
Frequency |
Memory |
EPC |
Alien H3 |
ISO18000-6C & EPC Gen2 |
860~960MHz |
512 Bit |
Up to 480 Bit |
Monza 3/4D/4E/4QT |
ISO18000-6C & EPC Gen2 |
860~960MHz |
64 Bit/32 Bit/128 Bit/512 Bit |
up to 496 Bit |
Ucode Gen2 |
ISO18000-6C & EPC Gen2 |
860~960MHz |
512 Bit |
240 Bit |
♦Picture of Cards
♦ Apllication of RFID Cards
-Access control: hotel door lock card, community management;
-Subway tickets/ city bus cards;
-Highway charging system cards, consuming system cards;
-Membership management system cards;
-School /campus/ library cards, students cards;
-Identity cards;
-Toll cards;
-Others.
♦Process
♦Exhibition
♦Packing & Shipping
♦Contact
Telephone: 86-755-89894425
Fax: 86-755-84521292
Address : 4&7/F, Building E, Longjing Industrial Park, Bantian Street, Longgang District, Shenzhen, China
Zip: 518129
