Custom Printing FM4428 Contact Card Oil Card

Name: Custom Printing FM4428 Contact Card Oil Card
Brand: Card Cube
SKU: 140587656
Availability: InStock

Shenzhen Card Cube Smart Technology Co., Ltd.

US$ 0.12 - 0.5 MOQ: 200 Pieces

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Card Cube

Model Number:

Contact Card-K-015

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name Card Cube

Model Number Contact Card-K-015

Custom Printing FM4428 Contact Card Oil Card

♦Products Detail

FM4428 Futures

100% functional compatibility to SLE 4428/SLE 5528

1024 x 8 bit EEPROM organization of Data Memory

1024 x 1 bit Protection Memory

Data Memory alterable only after verifi cation of 2 Byte PSC

PSC verifi cation trials limited by Error Counter

Ambient temperature range -40 to +100°C

EEPROM endurance of minimum 10,000 write / erase cycles

Data retention of minimum 10 years

Advanced CMOS-technology optimised for security layout

Material	PVC
Size	*85.5mm54mm0.85mm*
Chipset	FM4428
Interface	ISO7816/ISO7816-3
User Memory	1K Byte
Read and Write	Yes
Surface	White no printing, Glossy with Overlay
Application	Public transportation; Access control; Event ticketing; Gaming & identity.
Application Printer Printable	Zebra Printer; Fargo Printer; Evolis Printer; Magicard Printer; Datacard Printer; Other kinds of ribbon printer can print.

♦Embedded Chips Available

Chip	SLE5542	SLE5528	AT24C02~1024	AT88SC
Interface	ISO7816	ISO7816	ISO7816	ISO7816
Memory	256 Byte	1K Byte	2k bit~1024K bit	2k bit~256k bit
Write Endurance	100.000 cycles	100.000 cycles	100.000 cycles	100.000 cycles
Data Retention Time	10 Years	10 Years	10 Years	10 Years
Programmable Security Code verification logic	YES	YES	NO	YES
Other Chips: JAVA Chip, CPU Chip, Dual-interface Chip,etc
